MERLIN LEGEND Communications System Release 6.0
System Programming 555-660-111
3 Common Administrative Procedures
Extensions
Console Display/Instructions
Assign or remove the specified line/trunk number.
!
Select
Assign a single line/trunk to the next extension or go to Step 5.
!
Select
Return to the System Programming menu.
!
Select twice.
Block Procedure
Console Display/Instructions
Specify the block of 20 lines associated with 20 buttons
!
on the system programming console.
Select
Assign or remove the line/trunk to or from the line button.
!
Save your entry.
!
Select .
or
.
.
Additional Information
You may continue to assign or remove lines/
trunks by repeating Steps 2 and 3.
Return to Step 2 to continue programming. The
next extension is displayed on Line 1.
Additional Information
Toggle the green LEDs next to each
line button on or off as required.
On = line/trunk or pool assigned to extension
Off = line/trunk or pool not assigned to extension
For Hybrid/PBX only:
The red LED indicates:
On = trunk assigned to pool
Off = trunk not assigned to pool
Issue 1
February 1998
Page 3-70
