MERLIN LEGEND Communications System Release 6.0
System Programming 555-660-111
1 Programming Basics
System Programming Console
Console Buttons
Use the 14 buttons located on either side of the console display area for system
programming. These buttons are arranged in two columns of seven buttons, as
shown in
Home
Menu
Figure 1–2.

Fixed Display Buttons

The top two buttons in each column have the same labels and functions
regardless of the screen display. This type of button is called a fixed display
button. Table 1–1
Table 1–1.
Button
Home
Menu
More
Inspct
Figure 1–2.
MENU MODE: Select Feature
Press HOME to Exit
Directory
Messages
Posted Msg
Alarm Clock
Timer

Display Buttons and Main Menu

describes the functions of the fixed display buttons.
Fixed Display Buttons
Function
Return to normal call-handling mode after you finish programming.
Display the main menu shown in
Display more items when a menu is continued on more than one
screen, indicated by an angle bracket ( 3 ) on the upper right of the
screen.
(Inspect) View a list of lines or extensions on which a feature is
programmed or the settings for a feature.
1
Sys Program
Maintenance
Ext Program
1
Figure 1–2.
Issue 1
February 1998
Page 1-7
More
Inspct
