MERLIN LEGEND Communications System Release 6.0
System Programming 555-660-111
2 Programming with SPM
Accessing SPM
With a Local or Remote Modem Connection
The method you use to access SPM by modem depends on whether you are
programming on site (locally) or from a remote location.
If you are on site, the modem must be connected to an 012 or 016 module
on the control unit. To establish a connection to the control unit's internal
modem, dial   .
If you are at a remote location, do one of the following:
Considerations
Review the following items before you begin the modem connection procedure.
Set the Programming Language
If you prefer to program in a language other than the current SPM language
setting, see
Modem Connections
You must make a data connection to a modem. The following modem dialing
commands are for Hayes and Hayes-compatible modems. These may not be the
commands your modem uses refer to the user guide that came with your
modem for specific information.
If the PC is in the same location as the control unit, type   .
If the PC is in a remote location and your system has activated the Remote
Access feature, type the following and press
— Place a call to the system on a Remote Access line, enter the barrier
code (if required), and dial the code for the internal modem (   ).
— Place a voice call to the system using the line to which the modem is
connected and ask the operator to transfer you to the modem (by
pressing Transfer, dialing   , then hanging up the telephone).
When you hear the modem answer tone, switch to data mode.
"Language" on page 2–41
— Without barrier codes type:
6U9U ; the remote access telephone number; and X  .
For example: 6U9U ! $$$ !"#ÃX
— With barrier codes type:
6U9U ; the remote access telephone number; the barrier code
preceded by a "W" and X  . The barrier code in the example below
is 555555.
For example: 6U9U ! $$$ !"#ÃX$$$$$$ÃX
2
2
:
.
Issue 1
February 1998
Page 2-18
