MERLIN LEGEND Communications System Release 6.0
System Programming 555-660-111
1 Programming Basics
System Programming Console
DSS Components
Covers
DSS Designation
Cards
DSS Buttons
Fixed Buttons
LEDs
Removable plastic covers to protect the designation cards. The top
cover protects the 50 DSS button labels. The lower cover fits over
the fixed buttons.
Cards for labeling the extension or feature assigned to each button.
Fifty buttons used for one-touch dialing of co-workers' extensions
to make or transfer calls. DSS buttons are also used to page
co-workers over speakerphones, to park calls, and to handle
outside calls.
Ten additional buttons, including Message Status, Direct Voice
Mail and three Page buttons. The five remaining buttons on the
first DSS are not used. If a second DSS is connected to the
console, the 10 buttons at the bottom of the second DSS are not
used.
Fixed Message Status button used with fixed Page buttons to see
which telephones have Message Lights on.
Fixed Page Buttons are three buttons used to select the pages of
extensions that the 50 DSS buttons represent.
(Light-Emitting Diodes) The lights that assist in checking feature
status.
1
Issue 1
February 1998
Page 1-6
