4 Common Administrative Procedures
Automatic Route Selection
Console Display/Instructions
Erase the current stop time ( xxxx ).
!
Enter the stop time for Subpattern B ( hh = 00 to 23, mm = 00 to 59).
!
Dial or type [ hhmm ].
Save your entry.
!
Select @‡r… .
Return to the System Programming menu.
!
Select @‘v‡ twice.

Pool Routing

Use this procedure to identify the trunk pools on which to route calls to area codes
and/or exchanges included in ARS tables.
A maximum of six routes (numbered 1 through 6) can be specified for each
subpattern. Pool routing is programmed for Tables 1 through 16. Tables 17 and
18, the Default Toll and Default Local tables respectively, cannot be changed.
NOTES:
1. In Release 6.0 and later systems, when routing for ARS 10*** and
101**** equal-access calls (Interexchange Carrier or IXC) from a
networked switch that is not connected to the public switched network
and only has private network trunks, the private network trunks must be
assigned to the main pool on the system where ARS is dialed. The ARS
access code for the caller's system must match that of the system where
the public switched network trunks are connected. For this reason,
consider using the same ARS access code for all systems in the private
network.
Additional Information
Press Drop.
4
Issue 1
February 1998
Page 4-374
