MERLIN LEGEND Communications System Release 6.0
System Programming 555-660-111
3 Common Administrative Procedures
Optional Group Features
Console/Display Instructions
Select Group Coverage.
!
Enter the number of the coverage group ( nn = 1 to 30).
!
Save your entry.
!
Select @‡r… .
Specify the extension.
!
YY
Assign or remove the extension from the coverage group.
!
Select @‡r… or
9ryr‡r .
Additional Information
Dial or type [ nn ].
xx = number entered in Step 4
If no DSS is attached:
SP: "Entering an Extension"
If DSS is attached:
Toggle the red LED on or
off as required. Go to Step 8.
On = extension is sender in coverage group
Off = extension is not sender in coverage group
You may continue to assign or remove
extensions from the coverage group by
repeating Steps 5 and 6.
Issue 1
February 1998
Page 3-147
