MERLIN LEGEND Communications System Release 6.0
System Programming 555-660-111
1 Programming Basics
Programming Procedures
Figure 1–7.

Data Entry Screen

A data entry screen prompts you to enter specific data or to make specific
choices. Data to be entered will be displayed with n s in the text. When n s appear
on the data entry screen they indicate data currently programmed for the feature.
An exception is the slot/port number which is displayed as sspp to distinguish the
2-digit slot number from the 2-digit port number.
Many screens show data entered on a previous screen, such as an extension or
trunk number. Within the programming procedures, this type of variable
information is shown with
When information to be entered varies in the number of digits required (for
example, a telephone number that can range from 7 to 20 digits), the data may be
displayed as an uppercase X or N.
Data entry screens may also contain menu selections. Instead of entering data
from the dialpad, you select options on the screen, such as
disable a feature. To select this type of option, press either the unlabeled display
button next to the option name, or the function key that corresponds to the option
name. Then your selection is highlighted. To program or save the highlighted
selection, you press the unlabeled display button next to
Option Selected
Prompt
Data Entry Area
s.
x
Issue 1
February 1998
Page 1-13
or , to enable or

( on the PC).
