3 Common Administrative Procedures

Extensions

Extensions
This section contains the following procedures:
Assigning outside lines or trunks to the buttons on a telephone (including
lines and trunks used for loudspeaker paging)
Copying line button assignments from one extension to an individual
extension or block of extensions
Assigning the following buttons on telephones (for Hybrid/PBX systems
only):
Identifying analog multiline telephones that do not have built-in
speakerphones (BIS) or Hands Free Answer on Intercom (HFAI) capability
Identifying analog multiline extensions that require pairing of extension
jacks to provide either the Voice Announce to Busy or voice and data
features
Assign Trunks or Pools to Extensions
Use this procedure to assign outside lines/trunks (connected to the control unit) to
specific buttons on each telephone. The lines/trunks assigned to a button on a
telephone are called personal lines.
This procedure is used only to change or add personal lines, Loudspeaker
Paging, or Pool buttons (Hybrid/PBX only) to telephones. See
or System Access Buttons" on page 3–75
Intercom (ICOM) or System Access (SA) buttons.
!
SECURITY ALERT
In Release 6.0 and later systems (Hybrid/PBX mode only), do not assign
private networked lines as personal lines on telephone buttons. Do not
assign pools of private network trunks (tandem PRI or tandem tie) to
telephones. Do not provide dial access to these pools. Use ARS to provide
access to a remote networked system's trunks for making outside calls.
System users can reach extensions on the remote system by using normal
inside calling procedures.
Individual lines/trunks can be assigned to a maximum of 64 extensions. Individual
pools can be assigned as a Pool button on a maximum of 64 extensions.
— System Access or Intercom Voice
— System Access or Intercom Ring
— System Access or Intercom Originate Only
— Shared System or Intercom Access
:
3
3
for procedures to add or change
Issue 1
February 1998
Page 3-65
"Assign Intercom
