Chapter 7 Managing Prompts, Grammars, Documents, and Custom Files

Attribute Types

Main Attributes

Attribute
Manifest-Version
Created-By
Crs-Version
Name
newline
digit
Attributes that appear in the main section are called main attributes. Attributes
that appear in individual sections are called per-entry attributes. Some attributes
appear in both the main and individual sections, in which case the per-entry
attribute value overrides the main attribute value for the specified entry.
Main attributes are the attributes that are present in the main section of the
manifest. They fall into three different groups:
• General main attributes: See the following table.
Description
The manifest file version. The value is a legitimate version number, as
described in the above spec.
The version and the vendor of the java implementation on top of which this
manifest file is generated. This attribute is generated by the jar tool.
The minimum CRS version release compatible with the AAR file.
Crs-version is the accumulation of the CRS release, CRS Service Release,
and CRS Engineering Special defined in that order. For example, if the AAR
file is compatible with CRS release 4.1(1)_Build705, SR1_Build001,
ES2_Build002, the Crs-Version would be defined as
4.1(1)SR1ES2_Build002. Only the last build number is taken. So for
instance, if the AAR file is compatible with CRS release 4.1(1)_build705,
SR1_Build001, then the Crs-Version is 4.1(1)SR1_Build001. As a last
example, if AAR file is compatible with CRS release 4.1(1)_Build705 and
above, then Crs-Version would be 4.1(1)_Build705.
Cisco Customer Response Solutions Administration Guide, Release 4.1(1)
Value
CR LF | LF | CR (not followed by LF)
{0-9}
Managing AAR Files
7-25
