Cisco Virtual Office – End User Instructions for
Cisco 1811 Router Set Up at Home or Small Office
Introduction
This document describes the end-user instructions to deploy the Cisco Virtual Office (CVO) for home or
small office use.
Cisco Virtual Office (CVO) solution offers a seamless home/small office experience comparable to
working in your company's central office. CVO features support secure, always-on wired and wireless
(WLAN) data connectivity, voice services, and video capabilities.
Setup Your CVO Hardware
In this section you will be able to identify the basic hardware configuration needed to install the CVO
solution in your home/office. This is a known working configuration to assist you in your initial set-up
and is not intended to cover all variations of home/office network environments. This guide is written
based on Cisco 1811 routers.
Ports on the CVO Router
It is important that you understand which ports on the back of your CVO router are used for what
purposes.
•
•
Americas Headquarters:
Cisco Systems, Inc., 170 West Tasman Drive, San Jose, CA 95134-1706 USA
FE1 to FE9: LAN Ports FE1 to FE9 are end-user device secure ports. Connect your
PC/Mac/Linux/IP phone equipment here.
FE0: Use the WAN/FE0 port to connect your CVO router to your Internet Service Provider (ISP)
device.
Advertisement
Related Manuals for Cisco CISCO1811
Summary of Contents for Cisco CISCO1811
- Page 1 FE1 to FE9: LAN Ports FE1 to FE9 are end-user device secure ports. Connect your • PC/Mac/Linux/IP phone equipment here. FE0: Use the WAN/FE0 port to connect your CVO router to your Internet Service Provider (ISP) • device. Americas Headquarters: Cisco Systems, Inc., 170 West Tasman Drive, San Jose, CA 95134-1706 USA...
- Page 2 SETUP YOUR CVO HARDWARE How to Connect Your Equipment This scenario shows an example of your company’s provided devices and the Internet Service Provider (ISP) device (modem/router) properly connected to a CVO 1811W router.s For detailed descriptions, see below Figure 1 Step-by-Step Instructions Follow these steps to connect your CVO router to the ISP device and to your PC Step 1...
-
Page 3: Configure Your Router
Configure Your Router Once you have set up your CVO hardware you will need to configure your router so that you can access the Internet and your company’s corporate network. After the Internet connectivity is established you need to follow the steps that invoke the Secure Device Provisioning (SDP) tool to communicate with your company’s core infrastructure and complete your CVO router's configuration. - Page 4 CONFIGURE YOUR ROUTER Figure 2 SDP Authentication If you’re using DHCP, to initiate the SDP process, go to the PC which is connected to the CVO router and open a browser window. Then type in the address bar: http://10.10.10.1/ezsdd/welcome. You will be prompted to authenticate, and you must use username/password cisco/cisco.
- Page 5 Figure 4 After you click Next you will see a Security Request confirmation window; select Yes to proceed. Authenticate yourself. Step 4 When the system attempts to connect to the corporate CVO management server, you are prompted to authenticate yourself. You must use the credentials provided by your network administrator Figure 5 When your authentication is accepted you will see the confirmation screen shown in Cisco Virtual Office –...
- Page 6 CONFIGURE YOUR ROUTER Figure 6 Confirmation Screen Select Next to proceed. CVO router auto-configuration. Step 5 You should now see the enrollment window and your CVO router will automatically download the configuration from the CVO management server Do not select any of the options on this screen. This will interrupt your CVO router Note configuration.
-
Page 7: Appendix A: Ccp Configuration
CONFIGURE YOUR ROUTER Figure 8 Renew IP Address Once you have a valid IP Address, open your browser and attempt to connect to an external Website. This should be something other than your company’s internal home page; e.g. www.cisco.com. If this is successful then proceed with testing an internal Website. Verify connectivity to your company’s corporate network. - Page 8 CONFIGURE YOUR ROUTER Figure 9 Welcome Screen Enter the desired login credentials and enable password, as well as the hostname and domain name for the router (Figure 10), then click “Next”. Cisco Virtual Office – End User Instructions for Cisco 1811 Router Set Up at Home or Small Office 78-18859-01...
- Page 9 CONFIGURE YOUR ROUTER Figure 10 Basic Configuration Specify “Secure Device Provisioning” as the method for provisioning the router, as SDP will be used for the bootstrap config (Figure 11), then click “Next” Cisco Virtual Office – End User Instructions for Cisco 1811 Router Set Up at Home or Small Office 78-18859-01...
- Page 10 CONFIGURE YOUR ROUTER Figure 11 SDP for Router Provisioning Choose the corresponding IP address assignment method (PPPoE or Static). For PPPoE, select the authentication method (CHAP or PAP), and provide the appropriate credentials provided to you by your ISP (Figure Cisco Virtual Office –...
- Page 11 CONFIGURE YOUR ROUTER Figure 12 PPPoE For Static IP addresses, specify the IP address and subnet mask to be used by the router (Figure 13). Cisco Virtual Office – End User Instructions for Cisco 1811 Router Set Up at Home or Small Office 78-18859-01...
- Page 12 CONFIGURE YOUR ROUTER Figure 13 Static IP Addresses Choose whether or not to create a default route (Figure 14), then click “Next”. Cisco Virtual Office – End User Instructions for Cisco 1811 Router Set Up at Home or Small Office 78-18859-01...
- Page 13 CONFIGURE YOUR ROUTER Figure 14 Default Route CCP Express displays a summary page of the basic configuration that you setup for the router. Click “Finish” to deliver it to the router (Figure 15 Figure 16). Cisco Virtual Office – End User Instructions for Cisco 1811 Router Set Up at Home or Small Office 78-18859-01...
- Page 14 CONFIGURE YOUR ROUTER Figure 15 Summary Page PPPoE Cisco Virtual Office – End User Instructions for Cisco 1811 Router Set Up at Home or Small Office 78-18859-01...
- Page 15 Access Registrar, Aironet, AsyncOS, Bringing the Meeting To You, Catalyst, CCDA, CCDP, CCIE, CCIP, CCNA, CCNP, CCSP, CCVP, Cisco, the Cisco Certified Internetwork Expert logo, Cisco IOS, Cisco Press, Cisco Systems, Cisco Systems Capital, the Cisco Systems logo,...
- Page 16 CONFIGURE YOUR ROUTER Cisco Virtual Office – End User Instructions for Cisco 1811 Router Set Up at Home or Small Office 78-18859-01...
