Operation Manual – HWPing
H3C S3100 Series Ethernet Switches

1.1.2 Test Types Supported by HWPing

Table 1-1 Test types supported by HWPing
Supported test types
ICMP test
DHCP test
FTP test
HTTP test
DNS test
SNMP test
Jitter test
TCP test
UDP test
Caution:
H3C S3100-SI series Ethernet switches do not support HWPing DNS tests.

1.1.3 HWPing Test Parameters

You need to configure corresponding test parameters for each type of HWPing test.
HWPing test parameters can be configured on HWPing client only. For the
configurations on HWPing client, refer to section
Table 1-2 HWPing test parameters
Destination address
(destination-ip)
Destination port
(destination-port)
Tcppublic test
Tcpprivate test
Udppublic test
Udpprivate test
Test parameter
Description
For these types of tests, you need to configure
HWPing client and corresponding servers.
These types of tests need the cooperation of
HWPing client and HWPing Server.
Do not perform a TCP, UDP or jitter test on a
well-known port (ports with a number ranging from
1 to 1023) or on a port with a port number greater
than 50000. Otherwise, your HWPing test may fail
or the service corresponding to the well-known
port may become unavailable.
1.2.2 HWPing Client
For TCP/UDP/jitter test, you must specify a
destination IP address, and the destination
address must be the IP address of a
TCP/UDP/UDP listening service configured on
the HWPing server.
For tcpprivate/udpprivate/jitter test, you must
specify a destination port number, and the
destination port number must be the port
number of a TCP or UDP listening service
configured on the HWPing server.
1-2
Chapter 1 HWPing Configuration
Configuration.
Description
