Operation Manual – FTP-SFTP-TFTP
H3C S3100 Series Ethernet Switches

2.2 TFTP Configuration

Table 2-1 TFTP configuration tasks
TFTP Configuration: A Switch
Operating as a TFTP Client
TFTP server configuration

2.2.1 TFTP Configuration: A Switch Operating as a TFTP Client

I. Basic configurations on a TFTP client
By default a switch can operate as a TFTP client. In this case you can connect the
switch to the TFTP server to perform TFTP-related operations (such as
creating/removing a directory) by executing commands on the switch.
the operations that can be performed on a TFTP client.
Table 2-2 Basic configurations on a TFTP client
Download a file from a
TFTP server
Upload a file to a TFTP
server
Enter system view
Set the file transmission
mode
Specify an ACL rule used
by the specified TFTP
client to access a TFTP
server

2.2.2 TFTP Configuration Example

I. Network requirements
A switch operates as a TFTP client and a PC as the TFTP server. The application
named switch.bin is stored on the PC. Download it (switch.bin) to the switch through
TFTP, and use the boot boot-loader command to specify switch.bin as the
application for next startup. Reboot the switch to upload the configuration file named
config.cfg to the work directory on the PC to back up the configuration file.
Item
Operation
tftp tftp-server get
source-file [ dest-file ]
tftp tftp-server put
source-file [ dest-file ]
system-view
tftp { ascii | binary }
tftp-server acl
acl-number
Configuration task
Basic configurations on a TFTP
client
For details, see the
corresponding manual
Command
2-2
Chapter 2 TFTP Configuration
Description
—
—
Table 2-2
Description
Optional
Optional
—
Optional
Binary by default
Optional
Not specified by default
lists
