Operation Manual – Smart Link-Monitor Link
H3C S3100 Series Ethernet Switches
Note:
Currently, member ports of a Monitor Link group cannot be dynamic link
aggregation groups.
If the uplink or downlink port in the Monitor Link group is a link aggregation group,
you cannot directly delete this aggregation group or change this aggregation group
into a dynamic aggregation group. To delete this aggregation group, you must first
unbind this aggregation group from the Monitor Link.

2.2 Configuring Monitor Link

Note:
Before configuring a Monitor Link group, you must create a Monitor Link group and
configure member ports for it. A Monitor Link group consists of an uplink port and one or
multiple downlink ports. The uplink port can be a manually-configured or static LACP
link aggregation group, an Ethernet port, or a Smart Link group. The downlink ports can
be manually-configured link aggregation groups or static LACP link aggregation groups,
or Ethernet ports.

2.2.1 Configuration Tasks

Table 2-1 Monitor Link configuration tasks

Creating a Monitor Link Group

Configuring the Uplink Port
Configuring a Downlink Port
2.2.2 Creating a Monitor Link Group
Table 2-2 Create a Monitor Link group
Enter system view
Create a Monitor Link group
Task
Operation
Chapter 2 Monitor Link Configuration
Required
Required
Required
Command
system-view
monitor-link group group-id
2-3
Remarks
Remarks
—
Required
