Operation Manual – Mirroring
H3C S3100 Series Ethernet Switches
Table 1-5 Configuration on the intermediate switch
Enter system view
Create a VLAN and enter
VLAN view
Configure the current
VLAN as the
remote-probe VLAN
Return to system view
Enter the view of the
Ethernet port connecting
to the source switch,
destination switch or
other intermediate switch
Configure the current port
as trunk port
Configure the trunk port to
permit packets from the
remote-probe VLAN
III. Configuration on a switch acting as a destination switch
1) Configuration prerequisites
The destination port and the remote-probe VLAN are determined.
Layer 2 connectivity is ensured between the source and destination switches over
the remote-probe VLAN.
2) Configuration procedure
Table 1-6 Configure remote port mirroring on the destination switch
Operation
Enter system view
Create a VLAN and
enter VLAN view
Configure the current
VLAN as a
remote-probe VLAN
Return to system view
Enter the view of the
Ethernet port connecting
to the source switch or
an intermediate switch
Operation
system-view
vlan vlan-id
remote-probe vlan
enable
quit
interface interface-type
interface-number
port link-type trunk
port trunk permit vlan
remote-probe-vlan-id
system-view
vlan vlan-id
remote-probe vlan enable
quit
interface interface-type
interface-number
Chapter 1 Mirroring Configuration
Command
Command
1-7
Description
—
vlan-id is the ID of the
remote-probe VLAN.
Required
—
—
Required
By default, the port type is
Access.
Required
Description
—
vlan-id is the ID of the
remote-probe VLAN.
Required
—
—
