urmet domus IPerCom 3.0.0 System Technical Manual For The Installer page 589

The following table shows the meaning of the fields for lift interface 1060/37.
General settings
Name
MAC Address
IP Address
Device Code
Location
Mode
Input 1
Name
Mode
Normally open input
Set Outputs in case of
Alarm
The "Add" buttons in the "Activations" and "Alarms" section have already been described in the paragraphs
Activations and Sending alarms to the Switchboard via relay actuator
The function of the "Add path" button has already been described in paragraph
MT124-032M
Name to assign to the Lift Interface.
MAC address associated with the Lift Interface.
IP address of the Lift Interface. Field visible only if a manual network
configuration has been set in the system parameters. Value not
editable.
Value not editable.
Position in the system topology: it is possible to move the Lift
Interface to another topological node.
It allows you to define the operating mode of the Lift Interface.
Modes are: "Lift Interface - RS485", "Lift Interface", "Relay Actuator
Mode". Default mode: "Lift Interface"
Table 84: General settings
Name to assign to the input.
Input operating mode. In bistable mode, the input is set as a switch
(on and off events). In monostable mode, the input is set as a button
(short and long pressure events): in this case the pressure time must
be entered.
If selected, the input is normally open, otherwise it is normally
closed.
If selected, it allows you to set which relays will be activated when
an alarm is triggered.
Table 85: General settings
inputs.
Creating the path.
