urmet domus IPerCom 3.0.0 System Technical Manual For The Installer page 220

Since in each apartment in the example there are a MAX video door phone and an Miro door phone, you
can allow the Miro door phone of the whole site to call the "Dental Practice" contact.
To do this, select the "Apartment station by mean of button T1" option to call it using button T1 of the
Audio Door Phone and/or the "Miro door phone by mean of button T2" option to call it using button T2.
Figure 265: contact that can also be called via the T1 button of the Miro doorphone of the entire site
In the case shown in the figure, the created contact can be called by means of button T1 of each Miro Door
Phone in the system.
To view the contacts that a Miro door phone can call, refer to the Miro door phone section in
Configuration parameters of IPerCom
The association of contact - T1, T2 and T3 buttons for the video door phone 1761/6 takes place in
the same way.
220
devices.
APPENDIX A:
MT124-032M
