urmet domus IPerCom 3.0.0 System Technical Manual For The Installer page 323

The following table helps you to understand the meaning of the fields:
Surname or
Company Name
Name/Other
information
Telephone
number
Description
Key codes
Door Code
Suspended
The number of digits of the Door Code can be changed from a minimum of 4 digits to a maximum of
8. For further details, see paragraph
The door opener code, besides being unique in the system, cannot be the same as other codes
already generated and increased by one unit. In fact these codes are reserved for the coercion alarm
generation (in addition to the entrance hall opening). For further details see the installation and
user manual of the Switchboard downloadable from
Door opener codes and related coercion alarm codes can be entered on call stations equipped with
numeric keypad, i.e. Call Module 1060/12-13-17-18-23 and Modular Entry Panel with 1060/48.
For security reasons, it may be necessary to make access to the doors available to non-residents in a
specific time interval: to do this, at the bottom of the screen it is possible to set a time interval for the
validity of the Key Codes and of the Door Codes, as highlighted below.
MT124-032M
Surname of the resident or company name. Maximum length: 32 characters.
Resident name or other information. Maximum length: 32 characters.
Telephone number associated to the not resident. Maximum length: 16
numeric characters.
Short description of the not resident.
Proximity key codes associated with the non-resident (up to three key codes
per user). The code must be unique in the plant. It is possible to choose
between 4 different types of key according to the device set to read the key
Door opener numeric code associated to the non-resident. The configurator
automatically generates a 4-digit code, which can be modified. The code
must be univocal in the system. The code must be univocal in the system..
If selected, access to all access points is not allowed with either the key code
or the door code.
Table 15: Not Resident fields
System
Figure 417: period of validity of the Key Codes and of the Door Codes
parameters.
www.urmet.com
323
