To call an apartment via the keypad of a Call Module or a Modular Calling Station with 1060/48 or
a Switchboard, it is recommended to use the logical or numeric or numeric block addressing,
described below.
The "Select" button in the "Image" section allows you to upload an image on the display of the Call
Module 1060/12-13-17-18-23 which is intended to provide the guest with a "visual" aid in reaching
the called apartment. The selected image appears as soon as the call is forwarded and disappears
when the call is ended. Supported file formats include the most common ones like jpg, bmp and png.
We recommend uploading images with an aspect ratio of 200x58 pixels: this way the image will not
be cropped. Once an image is uploaded, you can delete it using the "Delete" button.
N
UMERIC ADDRESSING TYPE
In numeric addressing, to call an apartment from Call Module or Modular Calling Station with 1060/48 or a
Switchboard, a numeric code must be entered from the keypad. You can set this code in automatic or
manual mode (see paragraph
"Settings" tab of the "Topology" tab appears as shown below:
As you can see, the "Numeric Code" field is automatically filled in by the configurator. If, on the other hand,
you choose the manual mode, the numeric code must be filled in by the installer.
Numeric codes with a maximum of 6 digits can be entered from the configurator.
MT124-032M
Global Settings for further details). In the first case, for each apartment the
Figure 483: "Settings" screen for numerical addressing
