urmet domus IPerCom 3.0.0 System Technical Manual For The Installer page 467

8.4.2.6 Mode 4: One MAX video door phone with configurator in "Acquisition" mode
Application case: The devices are already installed on the system. The configuration has already been
created/imported on a MAX video door phone and the same MAX video door phone
and all other devices have been added.
Pros: All MAX video door phones can be added to the configuration via an automatic
procedure that can be followed at the same time by several people (the presence of
more people speeds up the configuration creation).
Cons: It is necessary to keep one MAX video door phone with configurator in "Acquisition"
mode.
In this case, it is assumed that the system has already been installed and that the installer creates a
configuration as explained before, by adding only one MAX video door phone and other devices other than
MAX video door phones.
The other MAX video door phones will be added automatically upon request by the current MAX video door
phone.
1. Creation of the configuration and addition, to that configuration, of a selected MAX video door
phone and of other devices (except MAX video door phones) according to one of the modes
described above, and configuration distribution from the same MAX video door phone.
2. Start of the acquisition mode on the field from the selected MAX video door phone.
From the selected MAX video door phone go to the configuration menu, then to "System configuration" and
to "Start acquisition mode", as shown in the following figure:
MT124-032M
Figure 620: "Start acquisition mode" in the configuration menu
467
