urmet domus IPerCom 3.0.0 System Technical Manual For The Installer page 494

9.2.2 iPerTAlk system configuration
1. Switch off the IPerCom system.
2. Connect the PBX and phones to the switch in the IPercom system.
Figure 654: IPerCom connection diagram - iPerTAlk without iPerTAlk switch Ref. 1375/701
3. Power the system up.
4. Configure the iPerTAlk system as follows.
5. Wait until the PBX has started and that the PC has received the IP if a DHCP server is present in the
IPerCom system; otherwise, iPerTAlk
be reached from the network.
6. On your PC, open the web browser and type in the IP address.
7. Acquire the phones and assign the numbering (as per IPerCom configuration e.g. 90101, 90102,
90103, etc.).
8. In the Advanced System Configurations, add an IPerCom type Line.
9. Create an Inbound Routing Rule and add the IPerCom line as the destination Trunk.
10. Disable the IPerCom network in the system network parameters.
11. Set in "static" mode the WAN configuration of iPerTAlk with the IP address suggested by IPerCom.
Information on the specific configurations of the iPerTAlk system integrated with the IPerCom
system are reported in the iPerTAlk
494
Ipercom 7" Video door
phone
will assigns IP address 192.168.56.245 to itself to allow it to
Installation and configuration booklet.
IP phones
Ref. 1375/10 -/11 -/12
MT124-032M
