urmet domus IPerCom 3.0.0 System Technical Manual For The Installer page 566

Switchboard 1060/41
The following table shows the meaning of the fields for Switchboard 1060/41.
General Settings
Name
MAC Address
IP Address
Device Code
Location
566
Figure 719: Settings
Name to assign to the Switchboard.
MAC address associated with the PC on which the Switchboard
programme is installed.
IP address associated to the PC on which the Switchboard programme
is installed. Field visible only if manual network configuration is set in
system parameters. Value that can not be changed.
Value that can not be changed.
Position in the system topology: it is possible to move the Switchboard
to another topological node by pressing the "Move" button.
Table 65: General settings
MT124-032M
