Switchboard C is of competence for all apartment stations in apartments and for Call Module B while it is
not for Call Module A, as its topological path does not intercept the only Switchboard present in the
system. According to what is reported in paragraph
•
the Call Module B has a specific button to call the competence Switchboard C;
•
the video door phones in apartments have a specific button to call the competence Switchboard C;
Switchboard C (in day status) intercepts calls to video door phones made by both Call Module A and Call
Module B.
3.3.9 Summary table
Below is a summary table of what has been written above regarding the main services offered by the
IPerCom system and which concepts they are connected to (whether topological group or topological
path):
Topological Group
Contacts in address book of calling station with
display.
Contact propagation in address book of MAX video
door phones and Audio Door Phones
Activation rule propagation on the apartment
station
3.4 Main and secondary calling stations
The calling stations, according to the topological node where they are positioned, are divided into:
•
main, if placed on the site or block topological node;
•
secondary, if placed on the unit or floor topological node.
This difference is reflected in the audio settings of the apartment station, which allow assigning two
different ring tones for calls coming from the two different types of calling stations.
The calling station that can be divided into main and secondary are: Call Modules 1060/12-13-17-18-23,
Entry panel 1060/21-33-34-71-74-75 and Modular Entry Panel with 1060/48.
MT124-032M
Table 1: Services offered by the IPerCom system by group or topological path
"Competence Switchboards", this means that:
Topological Path
Access to resident entrances
Calling stations and RTSP cameras that can be
displayed from the video door phones (auto-on)
Competence Switchboards
