2.3 Call Module 1060/23
The Call Module 1060/23 is a call station with 3.5'' colour display, alphanumeric keyboard, and steel vandal
resistant front panel.
The graphic display allows access to various functions (such as the residents' address book, direct call to the
relevant switchboard, door opening via numeric code) and the display of a welcome message (the display is
switched on automatically by means of a proximity sensor).
The Call Module can independently control two different outputs: the first one used to open a pedestrian
door, the second one to control the gate of a driveway.
The device allows access to the pedestrian door and to the driveway also by means of an integrated
proximity key reader (with MiFare Plus technology) or user code on the alphanumeric keypad; in the latter
case, it also allows managing the anti-coercion function through which a silent alarm is sent to the
gatekeeper lodge exchange at the same time as the door is opened.
It is also possible to set access to the pedestrian door and the driveway through both the reading of a key
and the typing of a code (both enabled.
It can be used in both 50Hz and 60Hz systems.
2.4 Modular entry panel with 1060/48 Alpha
The Modular Entry Panel is a call station consisting of an Outdoor audio and video IP station 1060/48 with 2
call buttons, based on model 1168 with single-module mechanism. The entry panel can be extended up to a
maximum of 45 buttons on one row or 90 buttons on two rows by means of proper expansion modules
1168/4 and 1168/8.
The Modular Entry Panel can independently control two different outputs: the first one used to open a
pedestrian door, the second one to control the gate opening control unit of a possible driveway.
On the Outdoor audio and video IP station module 1060/48 there are 3 LEDs for signalling the system status
(call in progress, line busy, door open and other).
For more detail on configuration of the Modular Entry Panel with 1060/48, see "APPENDIX I: Modular
entry panel with 1060/48 Alpha"
It can be used in both 50Hz and 60Hz systems.
