Polycom ReadiManager LX100 Scheduling Administrator's Guide
Fields in the H.323 Services (IP) Form for an MGC-100
Fields in the H.323 Services (IP) Form for a Radvision MCU-30
80
6. When you are finished defining the service, click Update.
7. Click Return to return to the Equipment form.
For video codecs, Direct will now appear in the Default Service list.
8. Click Update to save the changes to the Equipment form.
9. Repeat steps 4 through 8 until all H.323 services are defined.
For an example of where to find these settings in the MGC Manager software, see
Where Services are Set in MGC Manager
Field Name
Service Name*
IP Address*
Alias*
Ports*
Prefix*
Use Gatekeeper?*
For an example of where to locate these settings in the Radvision MCU software, see
Where Settings You Need Are Defined in Radvision MCU-30 Software
Field Name
Service Name*
Channels*
Prefix*
Mode**
on page 84.
Description
The name of the H.323 service as defined in the MCU
configuration.
IP address connected to the service, as defined in the MCU
configuration.
Alias corresponding to the service, as defined in the MCU
configuration. This number may include 0-9, #, and *. The alias for
the MGC can be found in the Span tab of the H323 Service (see
Figure 5-3).
Number of IP connections available to the service.
Prefix for selecting this service. The Prefix for the MGC can be
found in the H.323 Service properties dialog (see Figure 5-2).
Indicates whether the MCU is registered with a gatekeeper (Yes
or No), and that the MCU alias will be used for calls.
Description
The name of the H.323 service as defined in the MCU
configuration. (Shown as "Description" in the Radvision software.)
Number of 64K channels.
Prefix for selecting this service. Figure Figure 5-8 shows where
the prefix can be found in the MCU-30 software.
Indicates whether CP—Continuous Presence (All see one)—or
SW—switching (See you, see me)—will be used. (Shown as
"Voice Activate Method" in the Radvision software.)
on page 89.
Setting Up Services
