Fields in the Zone Form

Defining a Pipe

© Polycom, Inc.
2. In the Zone Information list, click
3. In the Zone form, complete the following required fields:
• Name
• Description
• Area
4. Enter any additional information for this zone and click
information.
For details about individual fields,
Field Name
Zone Information
Name
Description
Area
Pipes are predefined paths between zones that indicate the limited bandwidth available
between zones. Internally, the pipe bandwidth limit is set to 64 Mbps. If your network
contains multiple zones, you must create pipes.
Polycom ReadiManager LX100 uses router emulation to predict which paths the
network routers will use when the actual calls are made. This enables the Network
Aware Scheduler to accurately determine whether enough bandwidth will be available
for the call. In order to make the right decisions, the Network Aware Scheduler must
understand the network topology. To ensure the scheduler makes the correct decisions,
network pipe and zone information are required entries.
For example, say you have three zones, A, B, and C. If you want to place a call from A
to C, but the pipe between A and C is too loaded, Network Aware Scheduler knows the
network routers will use the path from A to B to C.
Chapter 4 - Entering Network Topology Data
Add New.
Fields in the Zone
Description
Name of the zone. Be sure to use a name that has meaning to
users, as zones appear when users create schedules and
select resources.
Description of the zone. This description appears in the zone
list.
The area in which this zone is defined. Existing areas can be
selected from the drop-down list. If you want to use an area
that has not yet been created in
LX100 , exit this form and create the area.
Update to submit the
Form.
Polycom ReadiManager
