Setting Up an MCU In Polycom ReadiManager
LX100

Setting up an MGC 100 in Polycom ReadiManager LX100

© Polycom, Inc.
Set up for using an MCU with Polycom ReadiManager LX100 includes two main steps:
Creating a Resource record that defines the resource as a hub.
Creating an Equipment record associated with that hub for the MCU. In the
Equipment form, you provide details about the IP and login information for the
MCU, define the services used to communicate with the MCU, enter any IVR
settings, and other setting that define capabilities and limits of the MCU.
The MCU should already be configured. You will enter information in Polycom
ReadiManager LX100 based on the existing MCU configuration.
Although different MCUs have somewhat different capabilities and features, the overall
process of setting up each MCU in Polycom ReadiManager LX100 is similar. To help
you see how to set them up, examples of setting up two different MCUs are provided:
Setting up an MGC 100 in Polycom ReadiManager LX100
Setting up a Radvision MCU-30 in Polycom ReadiManager LX100
The steps below provide a general overview of how to set up an MGC 100 in Polycom
ReadiManager LX100. The parameter fields that appear for this model are described
under Parameter Fields for a Polycom MGC 100
1. Create a resource record for a hub. For details, see
page 52.
2. After you create the Resource, when prompted, click the
The Equipment Information form appears.
3. In the Equipment Category field, select Gateways, Bridges, MCU:
4. In the Equipment Description field, select the type of MCU (for this example,
Polycom MGC 100).
The screen refreshes and Equipment Parameter fields that need to be defined for
this MCU appear.
5. Enter the IP Address, Login Name, and Password for the MCU.
For the MGC, this is the IP address of the controller. (If you need to locate this IP
in MGC Manager, right-click on the MGC icon and select IP Configuration. The IP
Configuration dialog box will open, displaying the IP, Subnet Mask, and Default
Gateway.)
You will enter the IP addresses of individual H.323 cards by defining H.323
Services.
Chapter 5 - Setting Up and Working with Resources
on page 70.
Defining a Resource
Add Equipment
on
link.
69
