Fields in the Gateway Service Form

Setting Up H.323 Services (IP)

© Polycom, Inc.
Field Name
Service Name*
Prefix*
Channels*
H.320 Service
Name
H.323 Services define how MCUs and Video Codecs can be reached through an IP
address. The H.323 fields required vary, depending on whether you are defining the
service for an MCU or for a video codec, and depending on the specific equipment you
are defining.
To set up H.323 (IP) service for an MCU or a video codec
1. Open the Equipment form for the MCU or video codec. (For details, see
Equipment Associated with a Resource
2. Scroll down to the Equipment Parameter Information section of the Equipment
form.
3. Click the H.323 (IP) link.
4. For each H.323 service you want to define, click the
to see details of an existing H.323 Service, click the
the H.323 Service page.
5. Complete all required fields in the form.
The particular fields required vary, depending on whether you are defining an
MCU or a video codec. In addition, some equipment may have different required
fields. Examples of H.323 fields for two different MCUs and a Video codec are
described below, under:
Fields in the H.323 Services (IP) Form for an
Fields in the H.323 Services (IP) Form for a Radvision MCU-30
Fields in the H.323 Services (IP) Form for a Codec
Chapter 5 - Setting Up and Working with Resources
Description
Descriptive name of the gateway service
include the speed as part of the name.
E164 prefix for selecting this service, as specified in the MCU
properties. This is a unique ID for each of the gateway services
you define. Each speed will have a unique ID.
For an MGC, the prefix is labeled the "Session Profile ID (E164)"
for the Gateway Session Profile in the MGC Manager software.
Number of 64K channels allocated for the prefix.
Name of the H.320 service associated with the dial-in number. An
H.320 Service must also be defined for this MCU, using the name
that you specify here. Make sure that the name entered here
matches the H.320 Service name.
on page 63.)
. You may want to
Add New button. If you want
Parameter Set link to open
MGC-100.
Viewing
