Polycom ReadiManagerLX100 Administrator's Manual page 85

Fields in the Direct Service Form for an MCU
Fields in the Direct Service Form for a Codec
© Polycom, Inc.
In Polycom ReadiManager LX100, Direct Connect service must be defined in both the
MCU equipment record and the video codec equipment record.
Direct Connect must be configured in the MCU itself, as well as defined for the MCU
equipment record in Polycom ReadiManager LX100.
To set up direct connect service for an MCU or a video codec
1. Open the Equipment form for the MCU or video codec. (For details, see
Equipment Associated with a Resource
2. Scroll down to the Equipment Parameter Information section of the Equipment
form.
3. Click the Direct Service link.
4. If no Direct Service has been defined yet, click the
Service already exists, click the
page.)
5. For an MCU, enter a Service Name and select a Type. (For details, see
the Direct Service Form for an MCU
For a video endpoint, complete all required fields in the form. (For details, see
Fields in the Direct Service Form for a Codec
6. When you are finished defining the service, click Update.
7. Click Return to return to the Equipment form.
For video codecs, Direct will now appear in the Default Service list.
8. Click Update to save the changes to the Equipment form.
Field Name
Service Name*
Type
Field Name
Service Name*
Direct Connect
MCU*
Chapter 5 - Setting Up and Working with Resources
on page 63.)
Parameter Set
on page 77.)
Description
Name for the Direct Service. This name will appear in the list of
available MCU Services when you create a Direct service for an
endpoint.
The type of Direct Service: MPI, RS366, or T1
Description
Name of the service.
The MCU to which this codec will connect directly.
Add New button. (If a Direct
link to open the Direct Service
on page 77.)
Viewing
Fields in
77
