Table A-131: ADSP-SC58x SMPU9 MMR Register Addresses (Continued)
Memory Map- Register Name
ped Address
0x310A00A0 SMPU9_RIDA[n]
0x310A00A4 SMPU9_RIDMSKA[n]
0x310A00A8 SMPU9_RIDB[n]
0x310A00AC SMPU9_RIDMSKB[n]
0x310A00B0 SMPU9_RCTL[n]
0x310A00B4 SMPU9_RADDR[n]
0x310A00B8 SMPU9_RIDA[n]
0x310A00BC SMPU9_RIDMSKA[n]
0x310A00C0 SMPU9_RIDB[n]
0x310A00C4 SMPU9_RIDMSKB[n]
0x310A00C8 SMPU9_RCTL[n]
0x310A00CC SMPU9_RADDR[n]
0x310A00D0 SMPU9_RIDA[n]
0x310A00D4 SMPU9_RIDMSKA[n]
0x310A00D8 SMPU9_RIDB[n]
0x310A00DC SMPU9_RIDMSKB[n]
0x310A01A0 SMPU9_EXACADD[n]
0x310A01A4 SMPU9_EXACSTAT[n]
0x310A01A8 SMPU9_EXACADD[n]
0x310A01AC SMPU9_EXACSTAT[n]
0x310A01B0 SMPU9_EXACADD[n]
0x310A01B4 SMPU9_EXACSTAT[n]
0x310A01B8 SMPU9_EXACADD[n]
0x310A01BC SMPU9_EXACSTAT[n]
0x310A0220 SMPU9_REVID
0x310A0800 SMPU9_SECURECTL
0x310A0820 SMPU9_SECURERCTL[n]
0x310A0824 SMPU9_SECURERCTL[n]
0x310A0828 SMPU9_SECURERCTL[n]
0x310A082C SMPU9_SECURERCTL[n]
0x310A0830 SMPU9_SECURERCTL[n]
ADSP-SC58x/ADSP-2158x SHARC+ Processor Hardware Reference
Description
SMPU9 Region n ID A Register
SMPU9 Region n ID Mask A Register
SMPU9 Region n ID B Register
SMPU9 Region n ID Mask B Register
SMPU9 Region n Control Register
SMPU9 Region n Address Register
SMPU9 Region n ID A Register
SMPU9 Region n ID Mask A Register
SMPU9 Region n ID B Register
SMPU9 Region n ID Mask B Register
SMPU9 Region n Control Register
SMPU9 Region n Address Register
SMPU9 Region n ID A Register
SMPU9 Region n ID Mask A Register
SMPU9 Region n ID B Register
SMPU9 Region n ID Mask B Register
SMPU9 Exclusive Access IDn Address
SMPU9 Exclusive Access Status
SMPU9 Exclusive Access IDn Address
SMPU9 Exclusive Access Status
SMPU9 Exclusive Access IDn Address
SMPU9 Exclusive Access Status
SMPU9 Exclusive Access IDn Address
SMPU9 Exclusive Access Status
SMPU9 SMPU Revision ID Register
SMPU9 SMPU Control Secure Accesses Register
SMPU9 Region n Control Secure Accesses Register
SMPU9 Region n Control Secure Accesses Register
SMPU9 Region n Control Secure Accesses Register
SMPU9 Region n Control Secure Accesses Register
SMPU9 Region n Control Secure Accesses Register
ADSP-SC58x Register List
Reset Value
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000010
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
