Table A-140: ADSP-SC58x SPORT3 MMR Register Addresses (Continued)
Memory Map- Register Name
ped Address
0x31002398 SPORT3_CS3_B
0x310023A0 SPORT3_ERR_B
0x310023A4 SPORT3_MSTAT_B
0x310023A8 SPORT3_CTL2_B
0x310023C0 SPORT3_TXPRI_B
0x310023C4 SPORT3_RXPRI_B
0x310023C8 SPORT3_TXSEC_B
0x310023CC SPORT3_RXSEC_B
Table A-141: ADSP-SC58x SPORT4 MMR Register Addresses
Memory Map- Register Name
ped Address
0x31002400 SPORT4_CTL_A
0x31002404 SPORT4_DIV_A
0x31002408 SPORT4_MCTL_A
0x3100240C SPORT4_CS0_A
0x31002410 SPORT4_CS1_A
0x31002414 SPORT4_CS2_A
0x31002418 SPORT4_CS3_A
0x31002420 SPORT4_ERR_A
0x31002424 SPORT4_MSTAT_A
0x31002428 SPORT4_CTL2_A
0x31002440 SPORT4_TXPRI_A
0x31002444 SPORT4_RXPRI_A
0x31002448 SPORT4_TXSEC_A
0x3100244C SPORT4_RXSEC_A
0x31002480 SPORT4_CTL_B
0x31002484 SPORT4_DIV_B
ADSP-SC58x/ADSP-2158x SHARC+ Processor Hardware Reference
Description
SPORT3 Half SPORT 'B' Multichannel 96-127 Select
Register
SPORT3 Half SPORT 'B' Error Register
SPORT3 Half SPORT 'B' Multichannel Status Register
SPORT3 Half SPORT 'B' Control 2 Register
SPORT3 Half SPORT 'B' Tx Buffer (Primary) Register
SPORT3 Half SPORT 'B' Rx Buffer (Primary) Register
SPORT3 Half SPORT 'B' Tx Buffer (Secondary) Register 0x00000000
SPORT3 Half SPORT 'B' Rx Buffer (Secondary) Register 0x00000000
Description
SPORT4 Half SPORT 'A' Control Register
SPORT4 Half SPORT 'A' Divisor Register
SPORT4 Half SPORT 'A' Multichannel Control Register 0x00000000
SPORT4 Half SPORT 'A' Multichannel 0-31 Select Reg-
ister
SPORT4 Half SPORT 'A' Multichannel 32-63 Select
Register
SPORT4 Half SPORT 'A' Multichannel 64-95 Select
Register
SPORT4 Half SPORT 'A' Multichannel 96-127 Select
Register
SPORT4 Half SPORT 'A' Error Register
SPORT4 Half SPORT 'A' Multichannel Status Register
SPORT4 Half SPORT 'A' Control 2 Register
SPORT4 Half SPORT 'A' Tx Buffer (Primary) Register
SPORT4 Half SPORT 'A' Rx Buffer (Primary) Register
SPORT4 Half SPORT 'A' Tx Buffer (Secondary) Register 0x00000000
SPORT4 Half SPORT 'A' Rx Buffer (Secondary) Register 0x00000000
SPORT4 Half SPORT 'B' Control Register
SPORT4 Half SPORT 'B' Divisor Register
ADSP-SC58x Register List
Reset Value
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
Reset Value
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
0x00000000
