P11 group Protection parameters

Function
Name
code
Phase loss
P11.00
protection
Frequency-d
ecreasing at
P11.01
sudden
power loss
Frequency
decreasing
P11.02 ratio at
sudden
power loss
Description
0x00–0x11
Ones place:
0: Input phase loss protection disable
1: Input phase loss protection enable
Tens place:
0: Output phase loss protection disable
1: Output phase loss protection enable
0: Enabled
1: Disabled
Setting range: 0.00Hz/s–P00.03 (the Max.
frequency)
After the power loss of the grid, the bus
voltage drops
frequency-decreasing point, the VFD begins
to decrease the running frequency at
P11.02, to make the VFD generate power
again. The returning power can maintain the
bus voltage to ensure a rated running of the
VFD until the recovery of power.
Voltage class
Frequency-decrea
sing point at
sudden power loss
Note:
 Adjust the parameter properly to avoid the
stopping caused by VFD protection during
the switching of the grid.
 Prohibit the input phase protection to
enable this function.
-90-
to the sudden
110V 220V 460V
260V 240V 530V
Function parameters
Default Modify
○
0x10
○
0
10.00
○
Hz/s
