Using the measurement panel

The measurement panel provides tools for editing measurements on an image and the
ability to change what measurement properties are displayed.
The measurement panel is only displayed once the first measurement is placed on an
acquired or saved image. The panel is not available in acquisition. When playing back
a clip with measurements, you cannot interact with the panel until the clip is paused.
A measurement label will be displayed next to the measurement on the image. It will
display a unique caliper, the measurement label, number, and values associated with
the type of measurement placed.
Measurements on the image will be shown in the measurement panel on the left of the
control panel. Use the measurement panel to edit the measurements.
Expand or collapse
measurements and to delete, edit or change properties.
Important: You must pause a clip before you can place a new measurement or
interact with previously saved measurements.
Important: For an image in a patient exam that is transferring or committed to a
DICOM server, you cannot place a new measurement or edit a measurement's
properties.

To change measurement properties

Each measurement has its own set of measurement properties that you can modify.
Note: Not all measurements have additional parameters.
1 Tap the measurement that you want to modify in the measurement panel.
2 Tap the Properties button. The measurement properties screen is displayed.
the measurement panel to view your list of
