M-Mode clinical display
The M-Mode clinical display is similar to the 2D clinical display but with some
differences.
M-Mode clinical display
1. Image status area
2. Mode settings panel
3. Display map
4. Transducer orientation indicator
5. Sample gate
6. 2D scout window
7. M-Mode window
8. Focal zone indicator
232
Scanning
