Use this control to zoom in on an image during scanning or in review.
Tap the Zoom button to activate the adjustable zoom control. Tap the In or Out
button, or drag the slider. The zoom factor is displayed within a range from 1.0x to
8.0x on the Zoom button.
You can also use a two finger spread gesture within the image area to zoom in; once
activated, four arrows will be displayed indicating zoom is on. To zoom out, use a two
finger pinch gesture.
To view other areas of the zoomed image, pan the image by dragging one finger in any
direction within the image area.
A magnifier icon and location guide is shown in the image on the clinical display. The
location guide displays the original image area with a white inner area that represents
the visible zoom area.
You can save an image with the zoom state activated and if you load the image in
review, you can zoom again using the same control. If you wish to return to the image
in its original state with no zoom activated, tap Default from the zoom controls.
Please note the following:
The maximum zoom factor may be less depending on the image size and the
l
minimum physical size of the image that can be displayed
If you change presets while in the zoom state, the zoom state will be turned off
l
If your image contains measurements and annotations, the text is not enlarged
l
when zoom is activated
Controls in 2D 227
