Connector
Fuse box
AC In
Ethernet connector
USB connectors
Transducer interface
With the exception of the Ethernet network cable, cables being connected to the
ultrasound cart must be 3 m (9' 10") in length, or shorter.
Grab bars
Use the front and back grab bars when you are moving the system. Don't use them to
lift the system—they are not designed to bear the weight of the system.
System connectors
Note: Once a headphone jack is connected, the internal
speakers and HDMI audio will be disabled.
The fuse box is located between the main power switch
and the AC In socket, on the bottom of the back of the
system enclosure. The fuse box contains replaceable
fuses that must be replaced by a FUJIFILM SonoSite
service technician.
Connect the power cable here. Located on the bottom of
the back of the system enclosure.
Connect your network data cable here. Located on the
back of the computer enclosure.
Connect your USB equipped data storage device here. 2
located on the back and 2 on the side of the computer
enclosure.
Connect the transducer here. Slide the transducer down
into the transducer bay and lock into place.
Description
System components 33
