This control adjusts the input signal strength that is mapped to the spectral display.
Tap Dynamic Range to display the flyout. Adjust the slider up or down to obtain the
required setting.
You can increase or decrease the range in 5 dB increments. The setting is displayed
on the control for easy reference and the value is stored with the image.
Use this control to change the magnification level of the area that is shown when a
measurement or annotation is being placed.
Tap Presets to see the available presets and then select an appropriate set of
optimized image acquisition settings. This button is active during image acquisition in
every mode.
The list of presets includes the factory default presets as well as any custom presets
you have added to the system. All presets are mode, exam type, transducer, and user
dependent.
You can customize the preset values to your specific exam type. See "Exam types
and presets" on page 106.
