- Page 1 Quick Reference Notes – Daily Care 簡易操作 -日常保養 Apeos 5330 / 4830 Prepared by Customer Training Team © FUJIFILM Business Innovation Hong Kong Limited...
-
Page 2: Table Of Contents
Tray 1 and Bypass Tray 紙盤 1 及 手送紙盤 ..............3 Fusing Unit 熔著部組件 ....................5 Replacing Toner Cartridge 更換碳粉匣 ..................8 Scan QR Code OR Click here for more instruction. 請掃描 QR Code 或者點擊這裡查看更多使用説明。 For more online support information please visit 更多相關資料，請訪問以下網址： https://support-fb.fujifilm.com... -
Page 3: Clear Paper Jam 夾紙排解
夾紙排解 LEAR APER 自動雙面送稿裝置 1.1 D UPLEX UTOMATIC OCUMENT EEDER 1. 將送稿裝置左側蓋開啟到停止位置。 1. Open the document feeder left cover until it stops. 2. If the orginal is not caught in the entry of 2. 去除夾紙的原稿。 the document feeder, pull out the orginal. Page 1 of 9... - Page 4 3. 關閉送稿裝置左側蓋，直至發出「咔嚓」 3. Close the left cover of the document 聲，確認蓋的手邊位置和最深處沒有移 feeder until it clicks into place, and confirm 動。 that there is no space between the near or far side of the cover and the document feeder. 4. 未發現原稿時，抬起送稿台，去除原稿。 4.
-
Page 5: Tray 1 And Bypass Tray 紙盤 1 及 手送紙盤
紙盤 1 及 手送紙盤 1.2 T YPASS 1. Remove any paper from the Bypass Tray. 1. 將手送紙盤中放置的紙張全部去除。 2. Hold both sides of the Bypass Tray, then 2. 握住手送紙盤的兩側，從機身拉出。 pull it straight out of the main unit. 3. 把紙盤 1 從機身拉出。 3. - Page 6 5. Insert Tray 1 and Bypass Tray all the way 5. 把紙盤 1 及手送紙盤完全放入機身內。 into the main unit. Page 4 of 9...
-
Page 7: Fusing Unit 熔著部組件
熔著部組件 1.3 F USING 1. Lift the rear door release and pull open 1. 拉起釋放桿，同時開啟背面蓋。 the door. 2. 開啟熔著部組件的把手。 2. Open the tab of the fusing unit. 3. Remove any jammed paper. 3. 去除夾紙。 Page 5 of 9... - Page 8 4. Return the tab. 4. 將把手放回原處。 5. Open the paper guide on the fusing unit. 5. 開啟下方的滑槽蓋。 6. Remove any jammed paper 6. 去除夾紙。 Page 6 of 9...
- Page 9 7. Close the rear door. 7. 關閉背面蓋。 Page 7 of 9...
-
Page 10: Replacing Toner Cartridge 更換碳粉匣
更換碳粉匣 EPLACING ONER ARTRIDGE 1. 先確定裝置已經停止運作，然後開啟前 1. Make sure that the device is not operating, then open the front door. 蓋。 2. Hold the handle and pull out the toner 2. 握住拉桿，慢慢取出碳粉卡匣。 cartridge slowly. Page 8 of 9... - Page 11 3. Remove the new toner cartridge from the 3. 從包裝盒取出新碳粉卡匣。 packaging. 4. Gently shake the toner cartridge back and 4. 上下左右搖動碳粉卡匣六次。 forth six times. Caution: Do not touch the 注意：請勿觸摸滑蓋部位。 shutter. 5. Hold the cartridge with the arrow facing 舉起卡匣，使箭頭朝上，再慢慢地將卡匣 up, and push the cartridge in slowly until it 推入直至停下為止。...
