2 Tap a measurement from the list.
3 The measurement will be placed on the image. You can interact with the
measurement using the control panel.
You perform most measurements by using calipers that you drag into position.
An active caliper has a round highlighted handle. Tap the caliper to activate it.
4 While you are placing the measurement, a magnified view of the placement area is
displayed on the clinical display. The default magnification factor is 4x; change the
magnification factor by tapping the Magnify Scale button and using the Increase or
Decrease button.
A measurement label will be displayed next to the measurement on the image. It will
display a unique caliper, the measurement label, number, and values associated with
the type of measurement placed.
5 Measurements on the image will be shown in the measurement panel on the left of
the control panel. Use the measurement panel to edit the measurements.
Expand or collapse the measurement panel to view your list of
measurements and to delete, edit or change properties.
6 Tap Save Clip to save the entire clip or tap Save Frame to save a new single
frame.
