Quick start tutorial

This tutorial provides a high-level overview for acquiring and analyzing an image and
then exporting your data.
WARNING: Before using the Vevo MD Imaging System users must read and
observe the Safety Warning and Precautions listed in .
To acquire and export a 2D image and analysis
1 Turn the system on. See
2 Log in, or use the Guest button. See
3 Connect a transducer (see
The system begins acquiring 2D data. See
4 A new patient exam is created. To change the details of the exam, see
patient information" on page 182.
5 Refine your image using the various controls, see
"Controls in 2D" on page 222.
6 Tap Freeze to stop data acquisition, see
acquisition, tap Unfreeze.
7 To place a measurement on a paused clip, move to a frame where you would like to
place a measurement, tap Measurements and select your measurement type. Place
the measurement by dragging the calipers. See
8 Tap Save Frame to save a frame. See
9 Tap Review Images to review saved images. Double tap a thumbnail to load that
image into review.
16 Getting started
"Starting up and shutting down the system"
"Logging on for the first time"
"Transducers" on page 39), and select an exam type.
"Exam types"
"Freeze"
"Measurements"
"Saving images"
on page 22.
on page 147.
on page 55.
"Editing
"Scanning" on page 197 and
on page 268. To re-start
on page 282.
on page 269.
