This control adjusts the size of the sample gate in millimeters (mm). The control
adjusts the distance of the vertical line between the two calipers.
Tap the Gate Size button, then tap Up to increase the size, or tap Down to decrease
the size. You can also drag the handles up or down on the control panel to adjust the
gate size and position.
Use this control to change the magnification level of the area that is shown when a
measurement or annotation is being placed.
Tap Presets to see the available presets and then select an appropriate set of
optimized image acquisition settings. This button is active during image acquisition in
every mode.
The list of presets includes the factory default presets as well as any custom presets
you have added to the system. All presets are mode, exam type, transducer, and user
dependent.
You can customize the preset values to your specific exam type. See "Exam types
and presets" on page 106.
