The measurement parameters are updated on the measurement panel. See
the measurement panel"
Your IMT measurement should look like the following measurement on your image on
the clinical display:
= lumen/intima interface trace
= media/adventitia interface trace
10 You can edit either trace by tapping on a caliper and dragging it to your desired
location.
11 Tap Save Clip to save the entire clip or tap Save Frame to save a new single
frame.

To add an IMT measurement to an M-Mode image

Note: If the IMT measurement is not available, ask an Administrator to enable the
IMT Measurement Tools, see
Select your M-Mode image and load into review. Use the zoom control or pinch on the
M-Mode window to expand and enlarge the M-Mode data so you can view your
measurement area accurately.
on page 287.
"Measurements and annotations"
To add an IMT measurement to an M-Mode image
"Using
on page 132.
