FujiFilm VisualSonics Vevo MD User Manual page 243

Sets the image orientation, allowing you to align the image with the transducer. The
blue dot in the corner of the control panel image area and clinical display image
corresponds to this setting.
Tap either of the orientation controls to toggle the orientation between the following
options: Left/Right and Up/Down.
The Save Preset button is used to save all of the parameters being used in the current
mode. This allows you to apply these exact parameters again later using the Presets
button.
1 Begin scanning in the desired mode. Adjust the controls to optimize your image.
2 Tap Save Preset to save the current settings as a preset.
3 Enter the name of your preset in the displayed field and tap Done to save the
setting.
The new preset appears in the mode-specific flyout when you use the Presets control.
Controls in M-Mode 243
