- Page 1 Apeos™ C8180 Apeos C7580 Apeos C6580 Reference Guide Main Unit April 2021 GM1041E1-2 Ver. 1 FUJIFILM Business Innovation Corp.
- Page 2 This product uses eT-Kernel. eT-Kernel is a trademark of eSOL Co., Ltd. in Japan and other countries. Other company names or product names are registered trademarks or trademarks of each company. FUJIFILM and FUJIFILM logo are registered trademarks or trademarks of FUJIFILM Corporation. Apeos, ApeosWiz, DocuWorks, PaperSecurity, Smart WelcomEyes and TrustMarkingBasic are registered trademarks or trademarks of FUJIFILM Business Innovation Corp.
- Page 3 Notations in Manual The following symbols are used in this manual. Information that you must know and information that you should confirm before Important operation. Reference information for operation. Note Reference pages. Refer “ ” Names and inputs of folders, files, apps, and functions. Also reference pages of the manual.
-
Page 4: Before Using The Machine
Before Using the Machine Device Components Front Component Function Document Cover Holds a document in place. Document Glass Load a document here. Control Panel Consists of operation buttons, LED indicators, and the Touch Panel Display. Smart WelcomEyes(SWE) Motion Exits the Power Saver Mode when the machine detects Sensor user presence. - Page 5 Component Function Waste Toner Container Cover Open this cover to replace the Waste Toner Container. Paper Trays 1, 2, 3, 4 Load paper here. Locking casters Used to move this machine. Lower Left Cover Open this cover to clear paper jams. Paper Tray 5 (Bypass) Used for loading non-standard paper that cannot be loaded in Trays 1, 2, 3, 4.
-
Page 6: Lan Connection
Component Function Wireless Network Kit Used for connecting wireless network (Wi-Fi/Bluetooth) to the (optional) machine. Reset button Automatically switches the machine off when a current leakage is detected. LAN connection When connecting to the network port, keep the machine power switched off. Note When a connection failure occurs, it may be improved by setting [Disabled] in >... - Page 7 Component Function Handle Used to pull out the Transfer Unit. Transfer Unit Transfers toner images on the drum to paper. Cleaning Bar Clean the LED printheads. Lock Release Handle Release the lock to replace Toner Cartridges. Toner Cartridge Contains the toner (image forming powder). 2 Before Using the Machine...
-
Page 8: Control Panel
Control Panel Refer Reference Guide - Operations For Control Panel, refer to the Component Function Built-in IC Card Used to authenticate a user using an IC card. Reader (optional) Paper Clip Tray Used for placing paper clips and staples. Power Button The power switches on. -
Page 9: Print Area
Component Function USB memory slot Insert a USB memory device directly here. (optional) Note A memory card reader or a USB memory device cannot be connected to the USB memory slot with a USB cable. Note that the machine will not recognize the memory on a memory card reader or a memory device connected to a USB interface connector on the rear side of the machine when a USB memory device is already inserted in the USB memory slot. - Page 10 Larger than A3 Copying 297 x 432 max. Printing 317 x 480 max. Standard Printable Area (mm) A3 or smaller Area excluding a margin (4.1 mm) along all four edges of the paper. Larger than A3 Standard size 317 x 480 max. Custom Size Area excluding a margin (4.1 mm) along all four edges of the paper.
-
Page 11: Recommended Paper
Paper Recommended Paper Standard paper Paper name Paper type setting for paper Image processing Image quality Paper weight tray to the paper type guarantee (g/m Plain Plain (A) Monochrome, paper color To use paper other than the above, contact our customer support center or sales agency. Recycled paper Paper name Paper type setting for... -
Page 12: Handling Paper
Do not store paper under direct sunlight. Handling paper Do not use collected pieces of paper. Do not use wrinkled or folded paper. Do not load paper of different sizes or types in the same tray. ... -
Page 13: Loading Paper
Basic Operations of the Machine Loading Paper After loading paper, configure the Paper Tray settings on the Home screen. Important Do not place paper or other objects in the reserved space of the tray. It may cause paper jams or machine malfunction. - Page 14 When loading paper whose size is JIS B4 or larger, pinch the knob and lift the paper rear end guide, and set the guide into the hole for the indicated size. Pinch the two Guide Clips, and adjust to the correct paper size.
-
Page 15: Bypass Tray
The bottom face of loaded paper is the surface printed on. Loadable paper Paper size JIS B5 , A4 , Letter Single side 52 to 300 Paper weight (g/m printing Maximum number of sheets Tray 3 (sheets) (C paper) Tray 4 1,410 Pull out the Paper Tray until it stops. - Page 16 Loadable paper Paper size A3, 13 x 19" (330 x 483 mm),12.6 x 19.2" (320 x 488 mm)(long paper: more than 488 to 1,300) A6, Postcard (100 x 148 mm) Paper weight Single side 52 to 300 (long paper: 52 to 220) printing (g/m Maximum number of sheets...
- Page 17 Paper orientation when the flaps are closed: Flaps come at the right when viewed from the front of the machine Note Load envelopes with glue or seal as the flap is closed. The loadable envelope size is up to 428 mm for the length. Long paper Load paper one sheet at a time.
-
Page 18: Loading Documents
Loading Documents Document Feeder Loadable paper Paper size A3, 11 x 17" Custom size 84 x 140 mm to 297 x 432 mm Paper weight Single side printing 38 to 200 (g/m Double side printing 50 to 200 Maximum number of sheets (sheets) (C paper) Note When the Fax Kit is equipped, the loadable paper size is up to 600 mm for the length. -
Page 19: Document Glass
Open the Document Stopper. Note To prevent a document from being left behind, “Document Feeder Attention Light” is turned on from the beginning until the completion of a Scan job. After the Scan job is completed, the light blinks three times and then turns off. Document Feeder Attention Light Document Glass... -
Page 20: Tray Capacity
Single-sided printing Double-sided printing Paper size (mm) Width 100 to 330 100 to 330 Length 148 to 488 148 to 488 52 to 350 52 to 300 Paper Weight (g/m Long paper Single-sided printing Double-sided printing Paper size (mm) More than 488 to 1,300 More than 488 to 762 Paper weight Uncoated... - Page 21 Extension Tray Insert 2 extension trays until they stop. Note Pass them through over the guide at the rear side of the tray until they stop. Thin paper loading wire When it is difficult to load thin paper, install the wire. Note The tray capacity is 10 sheets.
- Page 22 Paper size (mm) Width 170 to 297 Length 148 to 488 52 to 350 Paper weight (g/m Catch Tray Fan The catch tray fan is equipped with a knob to adjust the airflow volume. Adjusting the airflow volume according to the paper volume to be output to the tray can prevent sheets from sticking each other. Leave the scale to “0”...
-
Page 23: Maintenance
Maintenance Consumables Consumables recommended by our company are manufactured under the standards suitable for this machine. Using consumables not recommended by our company may affect print quality or performance provided by the product. Use consumables that our company recommends for this machine. -
Page 24: Led Printhead
Do not take out or shake the Waste Toner Container before it is filled up. Accurate detection can become no longer possible, and the toner may be spilled from the Waste Toner Container. When replacing the Waste Toner Container, toner may spill and soil the floor. We recommend laying a ... - Page 25 Scanner Document cover, Document Glass, film, scanner glass Wipe off any dirt with the supplied cloth about once a month. When stains cannot be removed easily, wipe them lightly with the soft cloth slightly moistened with a thin neutral detergent solution.
-
Page 26: Paper Jams
While turning the rollers, wipe them with a soft cloth slightly moistened with water. Close the Top Cover of the Document Feeder and make sure that there is no gap on the front or rear of the cover. Paper Jams If paper is jammed, the machine stops and an alarm sounds. -
Page 27: Right Side
Right side Open the Lower Right Cover. Remove the jammed paper. Close the Lower Right Cover. Exit Depending on the optional units equipped in the right side of the machine, the method of paper removal differs. Refer Reference Guide - Optional Units. For optional units, refer to Paper Trays 1, 2 Pull out the Paper Tray where the paper jam occurred until it... -
Page 28: Duplex Automatic Document Feeder
Paper Trays 3, 4 Pull out the Paper Tray where the paper jam occurred until it stops. Remove the jammed paper. Pull out the Tray 3 and Tray 4. Pull out the unit [C], then open the handle and remove the jammed paper. -
Page 29: Transfer Unit
Pull up the front handle of the Top Cover and open the cover until it stops. Open the Left Cover until it stops. Left cover Remove the document. If the document is caught in the entry, remove the jammed paper from the Left Cover. If the document is caught in the exit area, lift the Document Feeder Tray and pull the document toward the exit. - Page 30 Warning The Fusing Unit is hot. It may cause burn injury. Do not touch this unit. Open the Front Cover. Turn the handle [2] of the Transfer Unit to the right until it becomes horizontal ( ) and pull the Transfer Unit out to the front until it stops ( Slowly pull out the paper in the arrow direction and remove Note...
- Page 31 [2d] Open the handle [2d] down and remove the jammed paper. Return the handle [2d]. Push the Transfer Unit to the rearmost position and turn the handle [2] to the left. Close the Front Cover. Long paper When paper remains on bypass tray of Large Capacity Tray Open the Upper Cover of the bypass tray and remove the jammed paper.
- Page 32 Open the handle [1d] upward. Turn the knob [1c] to the right and remove the jammed paper (lead edge). When paper is jammed in delivery unit Note When long paper is jammed, the error indicator and/or message displayed on the details screen may be different from the actual jam state.
-
Page 33: Main Specifications
Appendix Main Specifications This section lists the main specifications of the machine. Note that the specifications and the appearance of the product may change without prior notice. Note The specifications are not intended to guarantee the image quality performance and feeding performance of all papers. - Page 34 Item Specification First copy output time Monochrome 4.1 seconds (monochrome priority (A4 ) mode) Color 5.4 seconds (Color priority mode) Reduction/enlargement Size-for-size:1: 1 ± 0.7% Preset: 50%, 70%, 81%, 86%, 115%, 122%, 141%, 200% Variable: 25 - 400% (1% increments) Continuous copy speed Paper size A4/JIS B5...
-
Page 35: Print Function
Item Specification Weight (kg) Note Weight not including the Toner Cartridges and Top Output Trays. Space requirement Width 1,568 x Depth 793 (mm) Note Space requirement (of the minimum configuration) when the Catch Tray is installed to the main unit and the Bypass Tray is fully extended. Print Function Item Specification... -
Page 36: Scan Function
Item Specification Built-in fonts Standard outline fonts (Heisei Mincho W3, Heisei Kaku Gothic W5), 19 Western fonts Optional ® ® Adobe PostScript 3™kit Heisei 2 font version : 2 Japanese fonts (Heisei Mincho W3, Heisei Kaku Gothic W5), 136 Western fonts Morisawa 2 font version : 2 Japanese fonts (Ryumin L-KL, Gothic BBB Medium), 136 Western fonts... -
Page 37: Fax Function
Item Specification Box storage Supported TCP/IP (WebDAV, HTTP) protocol Output format Monochrome binary: TIFF, DocuWorks , PDF Grayscale: TIFF, JPEG , DocuWorks , PDF Full color: TIFF, JPEG, DocuWorks , PDF , high compression : When Internet Services is used : When Network Scanner Utility 3 is used Driver Compatible with TWAIN interface... - Page 38 Item Specification Scanning Standard 8 x 3.85 lines/mm, 200 x 100 dpi resolution Fine 8 x 7.7 lines/mm, 200 x 200 dpi Superfine 16 x 15.4 lines/mm, 400 x 400 dpi (400 dpi) Superfine 600 x 600 dpi (600 dpi) Coding method MH, MR, MMR, JBIG Transmission speed...
- Page 39 Item Specification Interface Ethernet 1000BASE-T/100BASE-TX/10BASE-T Duplex Automatic Document Feeder Item Specification Type 1 pass, 2 sided scanning Duplex Automatic Document Feeder Scan Speed (when Same as the continuous copy speed copying) Scan Speed (when Monochrome: 135 sheets/minute, Color: 135 sheets/minute scanning) (Single-pass duplex scanning: Monochrome 270 sheets/minute, Color 270 sheets/minute)
-
Page 40: Safety Notes
Safety Notes Refer User's Manual Also refer to Location of Warning and Caution Labels Reference Guide Main Unit... - Page 41 5 Appendix...
- Page 42 The locations of the labels for Finisher are explained using an illustration in which the Folder Unit is installed to Finisher C as an example. Reference Guide Main Unit...
- Page 43 Symbols Marked on the Machine DANGER, DO NOT USE DO NOT THROW A CAUTION, AND ENVELOPE TONER WARNING CARTRIDGE INTO AN OPEN FLAME CAUTION DO NOT USE DO NOT THROW (HEATED POSTCARDS WASTE TONER SURFACE) CONTAINER INTO AN OPEN FLAME DO NOT INSERT A DO NOT USE DO NOT THROW...
Need help?
Do you have a question about the Apeos C8180 and is the answer not in the manual?
Questions and answers
How do I photocopy a booklet? Need it A5 with staples
To photocopy a booklet in A5 size with staples on a FujiFilm Apeos C8180:
1. Load your original documents onto the Document Feeder or Platen Glass.
2. Tap [Copy] on the Services Home screen.
3. Scroll down to [Booklet Creation] in the features list.
4. Choose one of the booklet options (e.g., Create Left/Top Bound or Create Right Bound).
5. Select [Fold & Staple] if stapling is required.
6. Ensure the output paper tray supports A5 size and stapling (minimum supported size is A5 LEF).
7. Tap [Start] to copy.
Note: The optional Booklet Maker must be installed to enable folding and stapling.
