Summary of Contents for FujiFilm Revoria Press E1100
Page 1
Reference Guide Optional Units Revoria Press E1136 Revoria Press E1125 Revoria Press E1110 Revoria Press E1100 Revoria Press E1136P September 2024 GM1074E2-5 Edition 1 FUJIFILM Business Innovation Corp.
Page 2
Contents High Capacity Feeder C1-D2 High Capacity Feeder B1-S/C3-DS/C1-DS Air Suction Feeder C1-DS Interface Decurler Module D1 Inserter D1 High Capacity Stacker A1 Crease / Two-Sided Trimmer D2 Folder Unit CD2 Finisher D 10 Square Back Fold Trimmer D1 Reference Guide Optional Units...
Page 3
Preface A guide describing the operations for optional units, such as the Finisher. Refer • Descriptions for the following optional products are provided in different guides. - Offset catch tray, Simple catch tray: 'Reference Guide- Main Unit' - Print / scan function-related products: 'Reference Guide - Operations' - Print server and related products: Manual included in the product - IC card reader: Official site of our company •...
Page 4
High Capacity Feeder C1-D2 Device Components / Caution Labels Component Function Right Cover Open this cover to clear paper jams. High Capacity Tray (Paper Tray 6) Load paper here. High Capacity Tray (Paper Tray 7) Load paper here. Bypass Tray (Paper Tray 5) Refer ...
Page 5
Loading Paper Images are printed on the face side of the loaded paper. Pull out the Paper Tray toward you until it stops. Remove any paper remaining in the Paper Tray. If changing the Paper Size, adjust the guide position. Remove the 2 screws for the guide, and remove the guide from the Paper Tray.
Page 6
Paper Jams If paper is jammed, the machine stops and an alarm sounds. Follow the instructions displayed on the screen to remove the jammed paper. Gently remove the paper being careful not to tear it. If paper is torn while it is being removed from the machine, remove all the torn pieces making sure that none remain inside the machine.
Page 7
■Paper Jams at [1b] Open lever [1b] to the right ( 1 ), turn knob [1c] clock- wise ( 2 ) and remove the jammed paper ( 3 ). Return lever [1b]. ■Paper Jams at [1d] Open lever [1d] upward ( 1 ) and remove the jammed pa- per ( 2 ).
Page 9
Component Function Bypass Tray (Paper Tray 5) Load paper here. Error Indicator When paper jam occurs, the indicator is turned on. When the priority device indicator (top lamp) blinks, first of all perform the paper jam operation. Right Cover Open this cover to clear paper jams. Remaining Volume Indicator When the Paper Tray is in operation, the top lamp is turned on.
Page 10
Main Specifications Item Specification Paper size Standard size SRA3 (320 x 450 mm), 12.6 x 19.2" (320 x 488 mm) Postcard (100 x 148 mm) Custom size (mm) Width 100 to 330 Length 148 to 488 Note For long paper placed in the Bypass Tray, the maximum size is 330 x 660 mm. Paper weight (g/m B1-S Bypass Tray...
Page 11
Loading Paper Loading to High Capacity Tray Images are printed on the face side of the loaded paper. Important Do not load paper above the maximum fill line. It may cause paper jams or machine malfunction. Note • If the amount of the loaded paper is 100 sheets or less, the guides apply more pressure to the paper. It may cause the paper to be distorted, leading to paper jams.
Page 12
Postcard Setting Attach Postcard Kit to the Paper Tray to load paper with the width of 100 to 181 mm. Pull out the Paper Tray toward you until it stops. Remove any paper remaining in the Paper Tray. If the Kit is supplied with the Paper Tray, loosen the screw ( ) on the left side of the Paper Tray to re- move the Kit (...
Page 13
Load remaining sheets with the printed side facing up, and align the paper edges in the direction of the arrow ( Adjust the short-side paper guide to the correct pa- per size ( To leave a space, pinch the paper guide grip to move. To narrow, push the paper guide to move.
Page 14
Changing Paper Feeding Accuracy Enabling this function may improve print displacement when images are skewed (print position is displaced) even though plain paper with the paper weight of 220 g/m or less is correctly loaded. Note • If this function is enabled when paper other than thick paper and plain paper is used, the machine cannot feed the paper properly, resulting in paper jams.
Page 15
Loading to Bypass Tray Images are printed on the face side of the loaded paper. Important Do not load paper above the maximum fill line. It may cause paper jams or machine malfunction. Note • If the paper guide width is narrower or wider than the paper, it may cause paper jams. •...
Page 16
Fan the paper well and insert it along the paper guide all the way until it touches the back, with the printed side facing up. Secure the 4 screws of the paper guide. Special Media Setting ■Hole Punched Paper Orientation: Place the holes of paper on the right side when you face the front side of machine. ■Precut Tab Orientation: Place the tabs of paper on the left side when you face the front side of machine.
Page 17
Paper Jams Note The error indicator at the top of the machine is turned on. When the priority device indicator (top lamp) blinks, first of all perform the paper jam operation. If paper is jammed, the machine stops and an alarm sounds. Follow the instructions displayed on the screen to remove the jammed paper.
Page 18
■When Indicator E6 is Turned on (B1-S), when Indicator E7 is Turned on (C3-DS/ C1-DS) Pull out the Paper Tray 6 (or 7, or 9) toward you until it stops. Note Confirm that no paper is jammed inside the Right Cover before pulling it out. Remove the jammed paper.
Page 19
■When Indicator E3 is Turned on Open lever [1b] to the right ( 1 ), turn knob [1c] clock- wise ( 2 ), and remove the jammed paper ( 3 ). Return lever [1b]. ■When Indicator E4 is Turned on Open lever [1a] to the right ( 1 ), turn knob [1c] clock- wise ( 2 ), and remove the jammed paper ( 3 ).
Page 20
Inside the Right Side Cover (Left side at continuous feed configu- ration) Open the Right Cover. Remove the jammed paper. When Indicator E1 is Turned on ....................p.20 When Indicator E2 is Turned on ....................p.20 When Indicator E3 is Turned on ....................p.21 When Indicator E4 is Turned on ....................p.21 When Indicator E1 is Turned on ■...
Page 21
When Indicator E3 is Turned on ■ Open lever [1b] to the right ( 1 ), turn knob [1c] counter- clockwise ( 2 ), and remove the jammed paper ( 3 ). Return lever [1b]. When Indicator E4 is Turned on ■...
Page 22
Paper Feeding Unit (Right side at continuous feed configuration) When Indicator E5 is Turned on ■ Pull out the top cover toward you until it stops. Note Before pulling out the Tray, make sure no paper is jammed inside the right side cover. Open lever [2a] to the right ( 1 ) and lever [2b] upward ( 2 ), and remove jammed papers ( 3 ).
Page 23
Cleaning Machine • When you clean machine products, use the cleaning materials designated in every step. • To wipe with a wet cloth, use the soft cloth tightly wrung out of water. If the parts are not com- pletely dry, the machine may malfunction. •...
Page 24
Wipe the surface of roller 1 with the soft cloth tightly wrung out of water. Reinstall roller 1. Note Make sure that roller 1 is installed in the holder completely. Remove roller 2 by picking up the both ends of its pin. Wipe the surface of roller 2.
Page 25
Cleaning the Paper Feeding Unit in the High Capacity Tray Note • Do not press a roller during the cleaning, otherwise the roller may drop off. • Non-woven dry type fabric can be used effectively for cleaning paper dust. Open the Right Cover. Open lever [1a] to the right.
Page 26
Open lever [1d] upward. Clean behind lever [1d]. Wipe the roller surface with the soft cloth tightly wrung out of water. Lightly wipe paper dust off on the surface of the paper path. Return lever [1d]. Paper path surface Roller Close the cover.
Page 27
Air Suction Feeder C1-DS Device Components Component Function Bypass Tray (Paper Tray 5) Load paper here. Error Indicator When paper jam occurs, the indicator is turned on. When the priority device indicator (top lamp) blinks, first of all perform the paper jam operation. Right Cover Open this cover to clear paper jams.
Page 28
Main Specifications Item Specification Paper size Paper size Standard size SRA3 (320 x 450 mm), Paper weight 12.6 x 19.2" (320 x 488 mm) Postcard (100 x 148 mm) Custom size (mm) Width 100 to 330 Length 148 to 488 Paper weight (g/m Uncoated 52 to 350...
Page 29
Loading Paper Important Do not load paper above the maximum fill line. It may cause paper jams or machine malfunction. Note • Position the guides correctly to match the paper size. Incorrectly positioned guides may cause misfeeding and paper jams. •...
Page 30
Load remaining sheets with the printed side facing up, and align the paper edges in the direction of the arrow ( Adjust the short-side paper guide to the correct paper size ( To leave a space, pinch the paper guide grip to move. To narrow, push the paper guide to move.
Page 31
Insert the guide A into the slit on the interior side ( and the slit on the bottom ( ), and then tighten the screw of the guide to fix ( Insert the guide B into the slit on your side ( ) and the slit on the bottom ( ), and then tighten the...
Page 32
To mount the shutters, place the shutters on the origi- nal positions and expand them. Hang the edges of the shutters on the protrudes. Confirm that they are firmly fixed. Note Align the △ marks so that the shutters can be mounted in the cor- rect orientation.
Page 33
Interface Decurler Module D1 Device Components Component Function Error Indicator When paper jam occurs, the indicator is turned on. When the indicator blinks, first of all perform the paper jam operation. Curl correction button Press the button to correct paper curl. This curl correction function can be used during printing.
Page 34
Curl Correction The curl correction button is used to correct paper curl caused by heat and/or pressure. The curl correction button can be operated regardless of the machine state when the machine is Note • This curl correction function can be used during printing. •...
Page 35
Operations and Functions of Curl Correction Press the AUTO button to enter the [AUTO] mode. Indicator Mode Function AUTO Curl correction is automatically performed. It is recommended to use this mode basically. Optimum curl correction is per- formed according to the paper size and output direction.
Page 36
Paper Jams Note The error indicator at the top of the machine is turned on. When the indicator blinks, first of all perform the paper jam operation. If paper is jammed, the machine stops and an alarm sounds. Follow the instructions displayed on the screen to remove the jammed paper.
Page 37
Inserter D1 Device Components Component Function Error Indicator When paper jam occurs, the indicator is turned on. When the priority device indicator (top lamp) blinks, first of all perform the paper jam operation. Curl correction button Use this button when Interface Decurler Module is not installed or curl cannot be corrected even if the highest correction (or lowest correction) of Interface De- curler Module is performed.
Page 38
Main Specifications Item Specification Paper size Standard size SRA3 (320 x 450 mm), 12.6 x 19.2" (320 x 488 mm) Note Can be used by inputting the size. Custom size (mm) Width 182 to 330 Length 148 to 488 Paper weight (g/m 52 to 350 Note ...
Page 39
Loading Paper Load paper (blank paper or printed paper) to be used as an interleaf or cover. Inserter Tray is used to load paper used as an interleaf or cover, and print cannot be performed. Note • After removing all the paper from the Tray, and then load the paper again together with the paper you want to add.
Page 40
Paper Jams Note The error indicator at the top of the machine is turned on. When the priority device indicator (top lamp) blinks, first of all perform the paper jam operation. If paper is jammed, the machine stops and an alarm sounds. Follow the instructions displayed on the screen to remove the jammed paper.
Page 41
If you have difficulty in removing the papers, open lever [1c] to the right ( 1 ), turn knob [1b] counterclockwise ( 2 ), and remove the jammed paper ( 3 ). Return lever [1c]. Close the cover. ■When Indicator E3 is Turned on Open the Cover.
Page 42
High Capacity Stacker A1 Device Components Component Function Error Indicator When paper jam occurs, the indicator is turned on. When the priority device indicator (top lamp) blinks, first of all perform the pa- per jam operation. Sample button Press the button to output a sample to the Top Output Tray. Paper eject button Press the button to stop printing and take out outputs.
Page 43
Ground Fault Interrupter When not using for an extended period or when moving the unit, set the switch to the lower position to turn the Switch machine power off. Note Do not operate the switch under normal circumstances because it is turned off when a current leakage is detected.
Page 44
Outputting Paper Top Output Tray Banner Print Extension Kit Long paper can be loaded without its lead edge sticking out. Paper size (mm) Tray capacity (sheets) Width: 210 to 330 Length: 488 to 660 Important When paper exceeding the tray capacity is loaded, the Extension Tray may get broken. Note ...
Page 45
Install the wires on the U-shaped bar. Note As holding the U-shaped bar with a hand, insert the fixing devices firmly, and check that the wires will not come off from the U-shaped bar. Adjust the wire positions according to the size of paper to be output.
Page 46
Paper Jams Note The error indicator at the top of the machine is turned on. When the priority device indicator (top lamp) blinks, first of all perform the paper jam operation. If paper is jammed, the machine stops and an alarm sounds. Follow the instructions displayed on the screen to remove the jammed paper.
Page 47
■When Indicator E3 is Turned on Open the front upper cover. Open lever [1b] upward ( 1 ), turn knob [1a] counter- clockwise ( 2 ), and remove the jammed paper ( 3 ). Return lever [1b]. Open lever [2b] upward ( 1 ), turn knob [2c] counter- clockwise ( 2 ), and remove the jammed paper ( 3 ).
Page 48
■When Indicator E6 is Turned on Press the paper eject button. When lock is released, open the front lower cover. Pull out the stacker cart slowly and remove the jammed paper. Return the stacker cart slowly. Close the cover. ■When Indicator E7 is Turned on Remove the jammed paper that sticks out from the exit of the Top Output Tray.
Page 49
■When Indicator E8 is Turned on Open the front upper cover. Open lever [3b] upward ( 1 ), turn knob [3a] clockwise ( 2 ), and remove the jammed paper ( 3 ). Return lever [3b]. Close the cover. Check the curl direction of the jammed paper and correct the curl. Refer ...
Page 50
Crease / Two-Sided Trimmer D2 Device Components / Caution Labels Component Function Error Indicator When paper jam occurs, the indicator is turned on. When the priority device indicator (top lamp) blinks, first of all perform the paper jam operation. Waste full indicator When cut pieces need to be disposed, the indicator is turned on.
Page 51
Main Specifications Item Specification Two-sided Trim Paper size Standard size SRA3 (320 x 450 mm), 12.6 x 19.2" (320 x 488 mm) A4, Letter (8.5 x 11") Custom size Width 194 to 330 (mm) Length 210 to 488 (Cutting and crease: up to 386) Paper weight (g/m Uncoated 52 to 350...
Page 52
Cutting and Crease Area 210 to 488 mm 386 mm or less (trim and crease) 194 to 330 mm (trim) Trim 182 to 330 mm (crease) Feed direction a: 12 mm or more A=B: 6 to 25 mm b - e: 25 mm or more Crease Printing is not possible when less than 45 mm from the front edge.
Page 53
Waste Container When cut pieces need to be disposed, the waste full indicator is turned on. When it is turned on, dispose cut pieces. Note • Cut pieces can be disposed even during printing. • When cut pieces in the waste container become full, the waste full indicator changes from ON to blinking. Open the lower cover.
Page 54
Paper Jams Note The error indicator at the top of the machine is turned on. When the priority device indicator (top lamp) blinks, first of all perform the paper jam operation. If paper is jammed, the machine stops and an alarm sounds. Follow the instructions displayed on the screen to remove the jammed paper.
Page 55
■When Indicator E2 is Turned on Turn knob [2] counterclockwise and align the marks. Open lever [1a] downward ( 1 ) and open lever [1b] downward ( 2 ). Turn knob [1c] clockwise ( 1 ) and remove the jammed paper ( 2 ).
Page 56
■When Indicator E3 is Turned on Turn knob [2] counterclockwise and align it with the mark position. Open lever [2c] downward ( 1 ) and remove the jammed paper ( 2 ). Note Jammed paper may be hidden at the upper section. Return lever [2c].
Page 57
■When Indicator E5 is Turned on Open lever [3a] to the right ( 1 ) and open lever [3b] to the left ( 2 ). Turn knob [3c] clockwise ( 1 ) and remove the jammed paper ( 2 ). Turn knob [2f] counterclockwise ( 1 ) and remove the jammed paper ( 2 ).
Page 58
Open lever [4a] to the right ( 1 ), turn knob [2f] counter- clockwise ( 2 ), and remove the jammed paper ( 3 ). Note As holding the lever [4a] with a hand, turn knob [2f] and remove the paper.
Page 59
Open lever [3a] to the right ( 1 ) and open lever [3d] to the right ( 2 ). Collect cut pieces around the trimmer unit in the waste container using the waste collecting bar. If cut pieces cannot be collected in the waste container, move them by the waste collecting bar and remove them with hands.
Page 60
Folder Unit CD2 Device Components / Caution Labels Bottom Component Function Tri-Fold Output Tray Button Press the button to remove paper from the Tri-Fold Output Tray. The Tri-Fold Output Tray is opened when the lamp stops blinking and comes on and the lock is released.
Page 61
Paper Jams Note The error indicator at the top of the Finisher is turned on. When the priority device indicator (top lamp) blinks, first of all perform the paper jam operation. If paper is jammed, the machine stops and an alarm sounds. Follow the instructions displayed on the screen to remove the jammed paper.
Page 62
■When Indicator E11 is Turned on Open lever [2g] to the right ( 1 ), turn knob [2c] counter- clockwise ( 2 ), and remove the jammed paper ( 3 ). Return lever [2g]. ■When Indicator E12 is Turned on Pull out the Tri-Fold Output Tray [2d].
Page 63
Finisher D In this guide, “Finisher D6” and “Finisher D6 with Booklet Maker” are generally referred to as “Fin- isher D”. Device Components / Caution Labels Component Function Hole Punch Waste Container Punched pieces go in here. Refer For the discard method of waste in the waste container, refer to the label affixed on the machine.
Page 64
Component Function Booklet Tray Saddle stitch and single fold paper is ejected. Note When the Square Back Fold Trimmer is equipped, it is installed to the Square Back Fold Trimmer. Cover Open this cover to clear paper jams, replace the Staple Cartridge, remove jammed staples or dispose of cut pieces for punched holes.
Page 65
Item Specification Booklet Tray 20 copies (16 sheets per copy) Note • Mixed Size Stacking refers to a condition in which larger paper is stacked on top of smaller paper, such as A4 on top of JIS B5 or JIS B4 on top of A4. •...
Page 66
Item Specification Dimensions (mm) Finisher Width 855 x Depth 725 x Height 1,204 Finisher with Booklet Maker Width 892 x Depth 725 x Height 1,204 Note When Banner Print Kit is installed: • top output tray's angle (B) + Banner Print Extension Kit: Width +281 x Depth ±0 x Height +222 •...
Page 67
Outputting Paper Top Output Tray Loading Guide Place it on the Top Output Tray when using an envelope. Changing Angle Change the angle when output paper remains at the exit and paper full is detected immediately. Especially in the following case, paper full is likely to be detected, change the angle to the B posi- tion.
Page 68
■Banner Print Extension Kit Long paper can be loaded without its lead edge sticking out. Paper size (mm) Tray capacity (sheets) Width: 210 to 330 Length: 488 to 660 Important When paper exceeding the tray capacity is loaded, the Extension Tray may get broken. ■Extension Tray Push the Top Output Tray from the rear side as pinching the cap and remove the 4 caps at the front edge of the Top...
Page 69
Change the angle of the Top Output Tray to the lower fixed position (A). Install the wires on the extension trays. Note As holding the extension tray with a hand, insert the fixing devices firmly, and check that the wires will not come off from the extension tray.
Page 70
Staple Cartridge Replacing Staple Cartridge / Staple Waste Container Consumables recommended by our company are manufactured under the standards suitable for this machine. Using consumables not recommended by our company may affect print quality or performance provided by the product. Use consumables that our company recommends for this machine.
Page 71
Staple Jams If paper is not being stapled or if staples are bent, follow the procedures mentioned in the follow- ing pages. If the issue isn't resolved even after the procedure, contact your local representative. Paper is not stapled Staple is bent If the staple looks like any of the following images, contact your local representative.
Page 72
Open the cover of the unit and remove the jammed staples. Insert the unit into the original position. Close the cover. Staple Cartridges for Saddle Stitch Confirm that the machine is not operating, and open the Cover. Pull out Booklet Maker [3]. Hold the handle of the Staple Cartridge (R2)(R3) and pull it out.
Page 73
Insert the Staple Cartridge into the original position. Hold the handle and lightly press it up until you hear a click. Note Align the “” marks. Push in the Booklet Maker [3]. Close the cover. When Staple Cartridge for Side Stitch Comes off If the Staple Cartridge comes off from the unit due to fall during operation, etc., perform the fol- lowing steps.
Page 74
Turn it over as the handle is at the moved position and take out the Staple Cartridge from the unit. Remove the staples that stick out from the Staple Cartridge. Caution Please be very careful not to hurt your fingers, etc. when separating staples. Insert the Staple Cartridge into the unit.
Page 75
Paper Jams Note The error indicator at the top of the machine is turned on. When the priority device indicator (top lamp) blinks, first of all perform the paper jam operation. If paper is jammed, the machine stops and an alarm sounds. Follow the instructions displayed on the screen to remove the jammed paper.
Page 76
■When Indicator E2 is Turned on Open lever [1c] to the right ( 1 ), turn knob [1e] clock- wise ( 2 ), and remove the jammed paper ( 3 ). Note Jammed paper may be hidden at the upper section. Return lever [1c].
Page 77
■When Indicator E6 is Turned on Remove the jammed paper that sticks out from the exit of the Finisher Tray. Open and close the cover. Close the cover. Check the curl direction of the jammed paper and correct the curl. Refer ...
Page 78
■When Indicator E8 is Turned on Pull out Booklet Maker [3]. Note Confirm that paper is not jammed at the lever [3a] before pulling it out. Turn knob [3b] counterclockwise ( 1 ) and remove the jammed paper ( 2 ). Push in the Booklet Maker [3].
Page 79
Square Back Fold Trimmer D1 Device Components / Caution Labels Component Function Left Cover Open this cover to clear paper jams. Right Cover Open this cover to clear paper jams. Booklet Tray Outputs are delivered here. Note When Square Back is performed, a thin press mark parallel to the back is made.
Page 80
Main Specifications Item Specification Paper size According to saddle stitch / single fold of Finisher D Paper weight Booklet Tray capacity 20 copies (16 sheets per copy) Note • A maximum of 16 copies for 17 to 20 sheets, a maximum of 12 copies for 21 to 25 sheets, and a maximum of 10 copies for 26 to 30 sheets.
Page 81
Waste Container Note Dispose cut pieces while the machine is on. Confirm that the machine is not operating, and pull out the waste container. Hold the belt of the waste container and pull it out with both hands. Note Do not apply excessive load on the belt by twirling the container as holding the belt, etc.
Page 82
Paper Jams Note The error indicator at the top of the machine is turned on. If paper is jammed, the machine stops and an alarm sounds. Follow the instructions displayed on the screen to remove the jammed paper. Gently remove the paper being careful not to tear it. If paper is torn while it is being removed from the machine, remove all the torn pieces making sure that none remain inside the machine.
Page 83
Turn knob [3b] clockwise and remove the paper. Close the Left Cover. ■When Indicator E2 is Turned on Open the Left Cover. Remove the jammed paper. Close the Left Cover. ■When Indicator E3 is Turned on Open the Right Cover. Remove the jammed paper.
