1.1.4 Electrical Wiring - Control Cables

3 Phase
power
input
DC bus
+10Vdc
0/-10Vdc -
+10Vdc
0/4-20 mA
0/-10Vdc -
+10Vdc
0/4-20 mA
Illustration 1.2 Basic Wiring Schematic Drawing.
A=Analog, D=Digital
Terminal 37 is used for Safe Stop. For Safe Stop installation instructions, refer to the Design Guide.
* Terminal 37 is not included in FC 301 (except frame size A1). Relay 2 and terminal 29 have no function in FC 301.
** Do not connect cable screen.
Very long control cables and analog signals may in rare cases and depending on installation result in 50/60 Hz earth loops
due to noise from mains supply cables.
If this occurs, it may be necessary to break the screen or insert a 100 nF capacitor between screen and chassis.
The digital and analog inputs and outputs must be connected separately to the common inputs (terminal 20, 55, 39) of the
frequency converter to avoid ground currents from both groups to affect other groups. For example, switching on the
digital input may disturb the analog input signal.
8
®
VLT AutomationDrive Programming Guide
91 (L1)
92 (L2)
93 (L3)
95
PE
88 (-)
89 (+)
10Vdc
15mA
50 (+10 V OUT)
+
S201
53 (A IN)
ON=0/4-20mA
S202
OFF=0/-10Vdc -
+10Vdc
54 (A IN)
55 (COM A IN)
12 (+24V OUT)
13 (+24V OUT)
P 5-00
18 (D IN)
19 (D IN)
20 (COM D IN)
27
(D IN/OUT)
24V
0V
*
29 (D IN/OUT)
24V
0V
32 (D IN)
33 (D IN)
*
37 (D IN)
®
MG33MG02 - VLT
Switch Mode
Power Supply
24Vdc
130/200mA
- + -
24V (NPN)
0V (PNP)
24V (NPN)
(COM A OUT) 39
0V (PNP)
24V (NPN)
S801
0V (PNP)
ON=Terminated
OFF=Open
5V
24V (NPN)
0V (PNP)
S801
RS-485
(N RS-485) 69
Interface
24V (NPN)
0V (PNP)
(P RS-485) 68
24V (NPN)
(COM RS-485) 61
0V (PNP)
is a registered Danfoss trademark
(U) 96
(V) 97
(W) 98
(PE) 99
Motor
(R+) 82 Brake
resistor
(R-) 81
relay1
03
240Vac, 2A
02
01
* relay2
06
240Vac, 2A
05
400Vac, 2A
04
Analog Output
0/4-20 mA
(A OUT) 42
0V
RS-485
**
: Chassis
: Earth
