3-1-3

Installation Warnings

11.)Since the LOGIQ P3 weighs approximately 80 kg (176 lbs) without options, preferably two people
should unpack it. Two people are also preferable for installing any additional bulky items.
12.)There are no operator serviceable components. To prevent shock, do not remove any covers or
panels. Should problems or malfunctions occur, unplug the power cord. Only qualified service
personnel should carry out servicing.
NOTE: For information regarding packing labels, refer to LABELS ON PACKAGE.
13.)After being transported, the unit may be very cold or hot. If this is the case, allow the unit to
acclimate before you turn it on. It requires one hour for each 2.5×C increment it's temperature is
below 10×C or above 40×C.
Equipment damage possibility. Turning the system on without acclimation after arriving at site
DANGER
may cause the system to be damaged.
°C
60 55 50 45
°F
140 131 122 113
hrs
8 6 4 2
3-1-4

Safety Reminders

WHEN USING ANY TEST INSTRUMENT THAT IS CAPABLE OF OPENING THE
DANGER
AC GROUND LINE (I.E., METER'S GROUND SWITCH IS OPEN), DON'T TOUCH
THE UNIT!
If the unit is very cold or hot, do not turn on its power until it has had a chance to acclimate to
CAUTION
its operating environment.
To prevent electrical shock, connect the unit to a properly grounded power outlet. Do not use a
DANGER
three to two prong adapter. This defeats safety grounding.
Do not operate this unit unless all board covers and frame panels are securely in place.System
DANGER
performance and cooling require this.
OPERATOR MANUAL(S)
DANGER
The User Manual(s) should be fully read and understood before operating the LOGIQ P3 and
kept near the unit for quick reference.
ACOUSTIC OUTPUT HAZARD
DANGER
Although the ultrasound energy transmitted from the LOGIQ P3 probe is within FDA limits, avoid
unnecessary exposure. Ultrasound energy can produce heat and mechanical damage
3-2
PROPRIETARY TO GE
8
EVISION
Table 3-3 Time for Settlement
40 35 30 25 20
104 96 86 77 68
0 0 0 0 0
Section 3-1 - Overview
15 10 5 0 -5
59 50 41 32 23
0 0 2 4 6
LOGIQ P3 S
ERVICE
-10 -15 -20 -25 -30
14 5 -4 -13 -22
8 10 12 14 16
M
ANUAL
-35 -40
-31 -40
18 20
