LOGIQ Ultrasound System Leakage Current Limits

Leakage current limits for LOGIQ Ultrasound Systems are shown below for 100-120 Volt and 230-240 Volt mains.
NOTE: Open Grounding is also known as "Lift Ground".
Table 10-13: Leakage current limits for LOGIQ Ultrasound system operation on 100-
Leakage Current Test
Chassis/Enclosure Leakage
Type BF and CF Applied Parts
Type CF Applied Parts (sink
leakage)
Table 10-14: Leakage current limits for LOGIQ Ultrasound system operation on 230-
Leakage Current Test
Chassis/Enclosure Leakage
Type BF Applied Parts
Type CF Applied Parts
Type CF Applied Parts (sink
leakage)
10-14
PROPRIETARY TO GE
8
EVISION
120 Volt mains (US/Canada/Japan)
System
Power
On and Off
On (transmit)
On and Off
240 Volt mains
System
Power
On
On (transmit)
On (transmit)
On and Off
Section 10-7 - Electrical Safety Tests
Grounding/ Limit mA
PE Conductor
Open 0.3
Closed 0.01
Open 0.05
Closed 0.05
Grounding/ Limit mA
PE Conductor
Open and Closed 0.5
Open 0.1
Open 0.05
Closed 0.05
