Doppler Mode Checks

4-3-9-1

Preparations

1.) Connect one of the probes listed in
to the System probe connector.
2.) Turn ON the scanner (if it isn't turned on already).
Primary Menu
Frequency
Baseline
Quick Angle
Sweep Speed
PRF
SV Length
Angle Steer
Angle Correct
Spectral Invert
Wall Filter
PW Mode
B Pause
4-20
PROPRIETARY TO GE
8
EVISION
Figure 4-14 Controls available in Doppler Mode
Figure 4-15 Doppler Mode Screen Picture Example
Section 4-3 - General Procedure
3-6-6 "Available Probes" on page
B Pause
LOGIQ P3 S M
ERVICE ANUAL
3-26, in Chapter 3 Installation
Secondary Menu
Rejection
Dynamic Range
Display Format
Full Timeline
Trace Method
Trace Sensitivity
Trace direction
Modify, Auto Calcs
PW/CF Ratio
Duplex
Time Resolution
Colorize
Gray Map
Power Output
Auto Calcs
Spectral Average
Cycles, to Average
Gain
M/D Cursor
