Chapter 7

Diagnostics/Troubleshooting

Section 7-1

Overview

7-1-1

Purpose of Chapter 7

This section describes how to setup and run the tools and software that help maintain image quality and
system operation. Very basic host, system and board level diagnostics are run whenever power is
applied. Some Service Tools may be run at the application level. However most software tests are
required.
Section
7-1
7-2
7-3
7-4
7-5
7-6
PROPRIETARY TO GE
8
EVISION
Table 7-1 Contents in Chapter 7
Overview
Gathering Trouble Data
USB Quick Save
Screen Captures
Wire - LAN Network
Troubleshooting
Chapter 7 Diagnostics/Troubleshooting
Description
LOGIQ P3 S M
ERVICE ANUAL
Page Number
7-1
7-2
7-4
7-6
7-9
7-10
