Configuring the Bluetooth Printer

After loading the software, follow the steps below to configure the Bluetooth Printer.
1.) Select Start on the Taskbar
2.) Select Bluetooth
3.) Select My Bluetooth
4.) Select Entire Bluetooth Neighborhood
The device will search for the Bluetooth Printer.
5.) Select HP Officejet
6.) Select pair device
7.) Enter 0000 (four zeroes), the security code
8.) Select OK
NOTE: Wait for few seconds till the check mark is seen on the printer.
9.) Select Print properties
10.)Print Test page
11.)Select Start ---> Bluetooth
Assign standard print to any of the print keys. Refer User Manual.
